LΩGIC™ 16X36 QRG
6
CAT5 Linking The
LΩGIC™ 16X36 controller uses a signal patch implemented with a
CAT5/6 cable to link to other
LΩGIC™ 16X36 controllers (see Cable
Connections).
To use this product in Master/Slave mode, you must connect the master
and slave
LΩGIC™ 16X36 controller using the CAT5 link.
DMX Linking Each
LΩGIC™ 16X36 controller comes with a pair of RJ-45 to XLR 3
adapters for connection to a DMX universe (DMX controller and other
DMX products linked with a DMX connection). See Cable Connections
for a detailed pin out diagram.
LΩGIC™
Fixture
Connectivity
Each
LΩGIC™ product comes with a CAT5 cable to link it to the
LΩGIC™ 16X36 controller. You can connect the product directly to
any of the 16 output lines of the
LΩGIC™ 16X36 controller, or you
could make an extension to install the
LΩGIC™ product at a farther
location.
In this case, you can use an RJ-45 coupler or an RJ-45 splitter to
connect the
LΩGIC™ product to the extension cable. See Fixture
Connection Diagram for more details.
Splitter Each
LΩGIC™ product comes with an RJ-45 splitter to allow the
connection of two products to a single LED output port of the
LΩGIC™ 16X36 controller. You can use more than one splitter on a
single LED output as long as you respect the maximum load of 36
LEDs (12 LEDs per color). See Maximum Output Line Loading for
more details.
RJ-45
Terminator
To make an RJ-45 terminator, connect 120 ohms, ¼ W resistor between
pins 6 (green/white) and 7 (white/brown) of an RJ-45 plug.
Insert the terminator into the DMX Out RJ-45 jack of the last
LΩGIC™
16X36 controller, as shown in Product Connection Diagram.
