LΩGIC™ 16X36 QRG
10
RGB Mode Menu Options
Main Programming Steps Instructions
1. Play auto
RGB 1~10
SPEED 1~255
Choose from 20 automatic
programs
RGBL 1~10
2. Play custom CUSTOM 1~10
Choose from 10 user-defined
programs
3. Play static
STATIC
PLAYING
LALL
L-1~16
(Output Line)
RED
0~255 Configure and/or play a single step
program per output line
GREEN
BLUE
DIMMER
STROBE 0~20
4. Play schedule SCHEDULE PLAYING! Play scheduled program
5. DMX address 001~512 Sets DMX starting address
6. Personality
EFFECT 9-channel mode
RGB 3-channel mode
RGB+D 4-channel mode
RGB+DMS 6-channel mode
RGB+LINE 48-channel mode
RGB+LINE+DMS 51-channel mode
SOLID 1-channel mode
7. Edit custom
C-1~10
(Custom)
S-1~20
(Scene)
R
G
B
0~255
Combine Red, Green, and Blue to
generate a custom color
S 0~20 Set the strobe frequency
T
0~255
Set the on time
F Set the fading time
8. Settings
PASSWORD ON/OFF
Turn password protection on after
30 seconds of being idle
ALLOW EDIT
YES/NO
Enable/disable Custom program
editing
RESET ALL Default all settings
RESET CUSTOM Erase the custom programs
RESET SCHEDULE Erase the schedule
UPLOAD PASSWORD? [Enter Password]
Transfer custom programs from
master to slave units
CLOCK
TIME NOW
View the current DOW, date, and
time.
EDIT TIME
DOW SU~SA
Edit the DOW, date, and time
DAY 01~31
MONTH 01~12
YEAR 00~99
HOUR 00~23
MIN
00~59
SEC
Continues on the next page
