AC Power
The LΩGIC™ 16X36 has an auto-ranging power supply that can work
with an input voltage range of 100~240 VAC, 50/60 Hz.
Make sure that you are connecting this product to the proper voltage, as
per the specifications in this guide, the product’s User Manual, or on the
product’s sticker.
AC Plug The
LΩGIC™ 16X36 comes with a power input cord that enters
through a strain relief boot that is then hardwired to the inside of the
unit. The other end of the power cord is bare-ended. Please use the table
below to wire the new plug.
Connection Wire (US) Screw Color
(US)
Wire
(Europe)
AC Live Black Yellow or
Brass
Brown
AC Neutral White Silver or Gray Blue
AC Ground Green/Yellow Green Green/Yellow
Fuse
Replacement
1) Disconnect the product from the power outlet.
2) With a Phillips #2 head screwdriver, unscrew the fuse holder cap from
its housing.
3) Remove the blown fuse and replace it with a good fuse of the same type
and rating (F 10 A, 250 V).
4) Screw the fuse holder cap back in its place and reconnect power.
