RGB Mode DMX Values
EFFECT Channel Function
Value Percent/Setting
1
Red
000 ó 255
0~100%
Step Time When CUS. 01-10 in CH. 7 is activated
2
Green
000 ó 255
0~100%
Step Time When CUS. 01-10 in CH. 7 is activated
3 Blue 000 ó 255 0~100%
4 Dimmer 000 ó 255 0~100%
5
Color Macro +
White Balance
000
ó 010
011 ó 035
036 ó 060
061 ó 085
086
ó 110
111 ó 135
136 ó 160
161 ó 185
186 ó 210
211 ó 215
216 ó 220
221 ó 225
226 ó 230
231
ó 235
236 ó 240
241 ó 245
246 ó 250
251
ó 255
No Function
R: 100% G: Up
B: 0%
R: Down G: 100% B: 0%
R: 0%
G: 100% B: Up
R: 0% G: Down B: 100%
R: Up G: 0% B: 100%
R: 100% G: 0% B: Down
R: 100% G: Up B: Up
R: Down G: Down B: 100%
White 1: 3,200 K
White 2: 3,400 K
White 3: 4,200 K
White 4: 4,900 K
White 5: 5,600 K
White 6: 5,900 K
White 7: 6,500 K
White 8: 7,200 K
White 9: 8,500 K
6 Strobe
000 ó 004
005 ó 255
No Function
0~20 Hz
7
Auto + Custom
Programs
000 ó 020
021 ó 030
031 ó 040
041 ó 050
051 ó 060
061 ó 070
071 ó 080
081 ó 090
091 ó 100
101 ó 110
111 ó 120
121 ó 130
131 ó 140
141 ó 150
151
ó 160
161 ó 170
171 ó 180
181 ó 190
191 ó 200
201 ó 210
211 ó 220
221 ó 255
No function
Auto RGB 1
Auto RGB 2
Auto RGB 3
Auto RGB 4
Auto RGB 5
Auto RGBL 1
Auto RGBL 2
Auto RGBL 3
Auto RGBL 4
Auto RGBL 5
Custom 1
Custom 2
Custom 3
Custom 4
Custom 5
Custom 6
Custom 7
Custom 8
Custom 9
Custom 10
No function
8
Auto Programs
Speed
000 ó 255 Slow~fast
Continues on the next page
