ILUMINARC LΩGIC™ 16X36 User Manual
Page 11
LΩGIC™ 16X36 QRG
11
Continued from previous page
Main
Programming Steps
Instructions
8. Settings
(Cont.)
CALIBRATION
WHITE 1~9
R
G
B
0~255
Modify the White macros (RGB
mode)
RGB TO WHITE
Configure RGB to WHITE
values
RGB TO WHITE
YES/NO
[Yes] RGB TO WHITE defines
output color when RGB faders are
at “255”
[No] Max. intensity when RGB
faders are at “255”
9. Operation
DMX
Work with a DMX controller
SLAVE
Slave mode
EASY PLAY
Optional remote
10. Schedule
SUNDAY~SATURDAY
(Different schedules for
each DOW)
No. [1~10]
RGB
RGBL
CUSTOM
1~10
After selecting DOW, schedule #,
and program, enter starting and
ending time [00:00~23:59]
EVERYDAY
(Same schedule for
every DOW)
STATIC
PLAY NONE
11. Patch
PATCH 1~6
RGB
RGBL
CUSTOM
1~10
Used with optional controller
