TSP-10G3A1EER
DELTA ELECTRONICS, INC.
7 Revision:
S3
04/10/2007
www.deltaww.com
Module Electrical Pin Function Definition
Pin
Logic
Symbol
Name/Description
Note
1
GND
Module
Ground
[1]
2
VEE5
Optional -5.2V Power Supply --Not Required
3 LVTTL-I Mod_DeSel
Module De-select; When held low allows module to respond to
2-wire serial interface
4 LVTTL-O Interrupt
Bar
Interrupt Bar; Indicates presence of an important condition
which can be read over the 2-wire serial interface
[2]
5
LVTTL-I
TX_DIS
Transmitter Disable; Turns off transmitter laser output
6
VCC5
+5V Power Supply
7
GND
Module
Ground
[1]
8
VCC3
+3.3V
Power
Supply
9
VCC3
+3.3V
Power
Supply
10 LVTTL-I/O
SCL 2-Wire
Serial
Interface
Clock
[2]
11
LVTTL-I/O
SDA
2-Wire Serial Interface Data Line
[2]
12
LVTTL-O
Mod_Abs
Indicates Module is not present. Grounded in the Module
[2]
13
LVTTL-O
Mod_NR
Module Not Ready; Indicating Module Operational Fault
[2]
14
LVTTL-O
RX_LOS
Receiver Loss Of Signal Indicator
[2]
15
GND
Module
Ground
[1]
16
GND
Module
Ground
[1]
17
CML-O
RD-
Receiver Inverted Data Output
18
CML-O
RD+
Receiver Non-Inverted Data Output
19
GND
Module
Ground
[1]
20
VCC2
+1.8V Power Supply --Not Required
21 LVTTL-I P_Down/RST
Power down; When high, requires the module to limit power
consumption to 1.5W or below. 2-Wire serial interface must be
functional in the low power mode.
22
VCC2
+1.8V Power Supply --Not Required
23
GND
Module
Ground
[1]
24 PECL-I RefCLK-
Reference Clock Non-Inverted Input, AC coupled on the host board,
Not required
25 PECL-I RefCLK+
Reference Clock Inverted Input, AC coupled on the host board,
Not required
26
GND
Module
Ground
[1]
27
GND
Module
Ground
[1]
28 CML-I
TD- Transmitter
Inverted
Data
Input
29 CML-I
TD+ Transmitter
Non-Inverted Data Input
30
GND
Module
Ground
[1]
Notes:
1. Module ground pins Gnd are isolated from the module case and chassis ground within the module.
