479
4-3. Do-it-yourself maintenance
4
Mai
n
tenan
ce and care
PRIUS_U (OM47685U) DVD
FUSE Ampere Circuit
25 RR WIP 20A Rear window wiper and washer
26 WIP 30A Windshield wipers
27 MET 7.5A Gauges and meters
28 IGN 10A
Brake system, driver support sys-
tem, multiport fuel injection sys-
tem/sequential multiport fuel
injection system, SRS airbag sys-
tem, occupant detection sensor,
power windows, smart key system
29 PANEL 10A
Air conditioning system, emer-
gency flashers, seat heaters,
transmission, “P” position switch,
navigation system, Solar Ventila-
tion System, Remote Air Condi-
tioning System, advanced parking
guidance system, headlight
cleaner, front passenger’s seat
belt reminder light, headlight level-
ing system, glove box light, clock,
audio system
30 TAIL 10A
Headlight leveling system, park-
ing lights, tail lights, license plate
lights, front fog lights, side marker
lights
