476
4-3. Do-it-yourself maintenance
PRIUS_U (OM47685U) DVD
FUSE Ampere Circuit
28 MIR HTR 10A Outside rear view mirror defoggers
29 RAD NO.1 15A Audio system, navigation system
30 DOME 10A
Door courtesy lights, personal
lights, interior lights, front foot
lights, vanity lights, inside rear
view mirror, garage door opener,
electric power steering
31 ECU-B 7.5A
Smart key system, multiplex com-
munication system, personal
lights, gauges and meters
32 H-LP LH HI 10A Left-hand headlight (high beam)
33 H-LP RH HI 10A Right-hand headlight (high beam)
34 EFI NO.2 10A
Multiport fuel injection system/
sequential multiport fuel injection
system
35 IGCT NO.3 10A Cooling system
36 SPARE 30A Spare fuses
37 SPARE 10A Spare fuses
38 SPARE 7.5A Spare fuses
39 EFI MAIN 20A
Multiport fuel injection system/
sequential multiport fuel injection
system, EFI NO.2
40 BATT FAN 10A Battery cooling fan
41 IG2 20A
Multiport fuel injection system/
sequential multiport fuel injection
system, MET-IGN, IGN, power
windows
