475
4-3. Do-it-yourself maintenance
4
Mai
n
tenan
ce and care
PRIUS_U (OM47685U) DVD
FUSE Ampere Circuit
13 AM2 7.5A Power management system
14 ECU-B2 7.5A Smart key system
15 MAYDAY 10A Mayday
16 ECU-B3 10A Air conditioning system
17 TURN & HAZ 10A Turn signal lights
18 ETCS 10A
Multiport fuel injection system/
sequential multiport fuel injection
system
19
ABS MAIN
NO.1
20A Anti-lock brake system
20 P/I 2 40A
Parking control system, horn,
right-hand headlight (low beam),
left-hand headlight (low beam),
back-up lights
21 ABS MTR 1 30A Anti-lock brake system
22 ABS MTR 2 30A Anti-lock brake system
23 H-LP HI MAIN 20A
H-LP HI RH, H-LP HI LH,
headlight switch, daytime running
light system
24 P/I 1 60A IG2, EFI MAIN, BATT FAN
25 EPS 60A Electric power steering
26 PCU 10A Inverter and converter
27 IGCT NO.2 10A
Hybrid system, parking control
system, power windows, inverter
and converter
