478
4-3. Do-it-yourself maintenance
PRIUS_U (OM47685U) DVD
FUSE Ampere Circuit
15 P FR DOOR 25A Power windows
16 D FR DOOR 25A Power windows
17 DOOR RR 25A Power windows
18 DOOR RL 25A Power windows
19 S/ROOF 30A Electric moon roof
20 ECU-IG NO.1 10A
Electric cooling fans, multiplex
communication system
21 ECU-IG NO.2 10A
Driver support system, Pre-Colli-
sion System, LKA system, inside
rear view mirror, garage door
opener, yaw rate & G sensor,
brake system, electric power
steering, navigation system, elec-
tric moon roof, tire pressure warn-
ing system, seat belt
pretensioners, audio system,
emergency flashers, turn signal
lights, windshield wipers, headlight
cleaner
22 GAUGE 10A
Headlight leveling system, front
passenger’s seat belt reminder
light, gauges and meters
23 A/C 10A
Air conditioning system, Solar
Ventilation System, Remote Air
Conditioning System
24 WASHER 15A Windshield washer
