Front panel, Rear panel – D-Link DSL-500 User Manual

Page 13

DSL-500 ADSL Router User’s Guide

Front Panel

Place the Router in a location that allows a view of the LED indicators on the front panel.

Rear Panel

All cable connections to the Router are made at the rear panel. The power switch and factory reset button is
located here as well.

RJ-14 console port used

for configuration (requires
RJ-14 to RS-232 adapter)

Ethernet port, connect

Ethernet cable here

Reset button

ADSL port, connect

ADSL cable here
