4 FORM NO. L-21156-F-0209
General SPeCIFICaTIOnS
Specifications
Torque: Up to 4785.9 Nm (42,350 in-lb)
Min. Release Pressure: 4.1 bar (60 psi)
Service Temperature:
4.5 - 50 C (40 - 120 F)
Approximate Weight: 50.8 kg (112 lbs)
General SaFeTy PreCauTIOnS
WARNING
Keep indoors. This product is
intended for indoor environments
only. Use of the brake outdoors
will damage components.
WARNING
Heavy object. To avoid injury,
use lifting aids and proper lifting
techniques when installing,
removing or replacing.
DANGER
WARNING
Do not stand on the brake guard
(or any other part) of the unit.
The components may fail and
cause severe injury or death.
CAUTION
Hot surface.
Do not touch.
CAUTION
Watch for sharp features when
installing and servicing the brake.
The brake has complex and
machined edges.
Due to high spring forces and
possible pinch points, always
keep hands and fingers out of
the linkage assembly area,
