Operation
Operating Manual PSSnet GW1 MOD-CAN
1002693-EN-02
37
} If the password is changed and the new password is forgotten, you have no longer the
option to access the web server via the gateway. In this case, the gateway has to be
sent to Pilz and reset to the original delivery status. Thereby all settings will be lost.
Ensure that the (new) password is saved reliably once the password has been
changed.
} Ensure that the configuration with the passwords of the delivery status is saved before
changing the passwords.
1. Call up the web server.
2. Copy these files to a PC using FTP:
– eth_cfg.xml (Ethernet configuration),
– password.xml (user definition).
Exchange Gateway
When exchanging the Gateway, the current configuration should be saved first, so that the
configuration can be imported into the new Gateway.
Recommended procedure:
1. Call up the web server and save the configuration.
– Copy these files to a PC using FTP:
eth_cfg.xml (CANopen configuration),
password.xml (user definition).
2. Switch off the supply voltage.
3. Disconnect all cables from the Gateway.
4. Remove the Gateway from the mounting rail.
5. Install the new Gateway in accordance with the Installation Manual,
Installation [ 25] .
6. Incorporate the Gateway into the network, Set addresses and transmission rate [ 32] .
– Make sure that the settings for the IP address, device address and, if necessary,
transmission rate are exactly the same as they were on the old module.
7. Copy the configuration data to the new Gateway via FTP.
8. Restart the Gateway via the web server.
