Control Channel Data Stream Output
The scanner can output the data stream on the control channel. You can turn on this feature in the menu
Set C-CH Output. When it is active, the scanner will output the data stream whenever it is receiving a
control channel. Also, for Motorola analog systems, the scanner will output the low speed data stream
while receiving a voice channel.
Data Stream Output: ON
When data stream output is set to on, the scanner will output the data stream in the following format:
,.
Data Stream Output: Extend
When data stream output function is set to extend, the scanner will output the data stream in the
following format: ,.,.
=
ASCII character (3 chars):
MOT (Motorola)
EDW (EDACS Wide)
EDN (EDACS Narrow)
LTR
P25 (Motorola Digital)
=
OSW Data on Control Channel. It is deferent each Trunk System Type.
[MOT System]
MOT,,,
= command or LCN (Hex 3 digits, 10 bits)
= private bit (1 bit)
= ID (Hex 4 digit, 16 bits)
For example:
MOT,15C,0,D110
[ED Wide/Narrow]
EDW,,,
= block number in a OSW (0 or 1)
= command (Hex 2 digits, 6 bits)
= message (Hex 6 digits, 22 bits)
For example:
EDW,0,3B,238333
EDN,0,3B,238333
Note: For EDACS narrow systems, the indicator will change from EDW to EDN.
