Xblue Networks X16 - Manual (Page 57)

Issue 2 - 57 -
Fu
nc
tio
ns
Functions
Features and LED function
Feature Code Descriptive LED lit LED Not Lit
Feature +
 Record Active Not Recording
Feature +
 Open N/A N/A
Feature +
 Flash Key N/A N/A
Feature +
 DND Active Not in DND
Feature +
 Mute Active Not in Mute Mode
Feature +
 Conference N/A N/A
Feature +
 Pause N/A N/A
Feature +
 Redial N/A N/A
Feature +
 Headset Active Not Active
Feature +
 All Page Active Not Active
Feature +
 Open N/A N/A
Feature +
 Open N/A N/A
Lamp (LED) Cadence
Unlit Off
Lit Lit Solid
Fast 0.125 sec off, 0.125 sec on, repeating
Slow 0.5 sec off, 0.5 sec on, repeating
Wink 1 0.250 sec off, 1.750 sec on repeating.
Wink 2 0.250 sec off, 0.250 sec on, 0.250 sec off, 1.25 sec on repeating
Wink 3 0.250 sec off, 0.250 sec on, 0.250 sec off, 0.250 sec on, 0.250 sec off, 0.750
sec on, repeating.
Lamp (LED)s on Phone
CO Line Status My Station Other Stations
Idle Unlit Unlit
In-Use Lit Green (I-Use) Lit Blue (In-Use)
On Hold Slow Green (I-Hold) Lit Blue (In-Hold)
Ringing Fast Blue Fast Blue
Being Transferred Slow Green (I-Hold) Lit blue (I-Hold and Transfer)
Intercom Tone cadences
Dial Tone Continuous Tone
Busy Tone 0.5 sec on, 0.5 sec off, repeating
Ring Tone 1 sec on, 1 sec off, repeating
DND Tone 0.25 sec on, 0.25 sec off, repeating
