CMOS Camera
www.dtresearch.com
Installation
The CMOS Camera is preinstalled as an option.
To Test CMOS Camera Module
To test the CMOS Camera, launch DTSMCap from Start | All Programs | DT Research |
DTSMCap.
Click Options | Preview to start
to capture the picture.
Click on Snap or pre-assigned
trigger button to take a picture.
To capture the video, select
Capture | Start Capture to start,
and click Stop Capture to stop
the video capture.
4
4
4
Button Management
To assign Camera Trigger button, follow the procedures below.
1. Start Button Manager by clicking on in the system tray.
2. Select an available unused button marked with the icon .
3. Click on to go to the second screen of Button Manager.
4. Click on the icon to assign the Camera Trigger to the unused button.
5. Click OK to apply configuration settings and close the window.
CMOS Camera 1/2
Note: The product outlook will look slightly different on different models.
Camera
Camera
