WebDT DT432SC-MD User Manual
Handheld pos terminal, Basic operation guide
DT432SC-MD/ DT432SQ-MD
ENGLISH
Handheld POS Terminal
BASIC OPERATION GUIDE
DT432SC-MD/ DT432SQ-MD
ENGLISH
4
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
http://www.dtresearch.com
Copyright © 2014, DT Research, Inc.
All Rights Reserved. DT Research is a registered trademark of DT Research, Inc.
INTRODUCTION
Thank you for acquiring the DT432SC/ DT432SC-MD/ DT432SQ-MD. The DT432SC/
DT432SC-MD/ DT432SQ-MD offers a 4.3” capacitive touch display and built-in Wi-Fi
connectivity in a slim and lightweight package.
The DT432SC/ DT432SC-MD/ DT432SQ-MD has options for a barcode scanner, IR
temperature sensor and camera, and enables efficient point-of-service/ care applications,
inventory management, and field services.
PACKAGE CONTENTS
O
1. ne DT432SC/ DT432SC-MD/ DT432SQ-MD
O
2. ne battery pack
O
3. ne AC-DC adapter
Basic operation guide
4.
The actual package contents may vary depending on the configuration acquired.
*
PRECAUTIONS
Always exercise care when operating and handling the
•
DT432SC/ DT432SC-MD/
DT432SQ-MD.
Do not disassemble any portion of the
•
DT432SC/ DT432SC-MD/ DT432SQ-MD. It will
void any product warranty on DT432SC/ DT432SC-MD/ DT432SQ-MD.
Do not use any power adapter or charging cradle other than the one provided with the
•
device or acquired from the manufacturer or its partners.
In the unlikely event that abnormal noise, strange odor, or smoke is present,
•
immediately power down the DT432SC/ DT432SC-MD/ DT432SQ-MD and disconnect
all power sources. Please report the problem to your device provider immediately.
BOG072814DT432SC-MDDT432SQ-MDENG
ACCESSORIES:
Charging Cradle
Desktop cradle with rear pocket battery charger.
Input: 100 - 240V AC; output: 5V DC, 3A.
Battery
Replaceable, rechargeable Li-Ion battery 2500mAh, 3.7V.
Rubber Jacket
For handling protection.
Stylus
Stylus for capacitive display devices.
