Vortech 2003-2005 Lexus 3.0L IS300 - Manual (Page 6)

P/N: 4LA020-010
©2007 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
11JUL07 v1.1 Lexus(4LAv1.1)
vi
008110 SMALL SILVER DIE-CUT DECAL 2
008130 LICENSE PLATE FRAME, VORTECH 1
008444 S/C STRT INFO PKG ASY VORT 1
2E248-080 SUPERCHARGER V-5F SQ CW, LEXUS IS300 1
4LA020-010 INSTRUCTION MANUAL, IS300 1
4LA110-010 POWER STEERING COOLR ASY 1
8N006-025 COOLER, P/S 4-PASS PERMA/CL 1
8N100-001 NYLON MOUNTING KIT 1
7P375-312 3/8" BARB x 5/16" BARB REDUCER 2
7R004-003 STEPLESS CLAMP, 14.5-70 4
7U031-018 5/16" EFI FUEL HOSE HI-PSR 4'
4LA111-044 S/C MOUNT BRKT ASY, LEXUS IS300 1
2A017-462 SPACER, IDLER SMOOTH 6-RIB 1
2A017-501-153 SPACER, .50"OD x 1.538"L ALUM 1
2A017-750-08 SPACER, .75"OD x .1.437"L 1
2A017-875-13 SPACER, .875"OD x .895"L 5
2A046-100 BELT, GATES K061010 1
4FA016-171 DUST COVER (IDLER PULLEY) 2
4FH016-150 IDLER PULLEY, 6-RIB 3" FLANGED 2
4LA010-010 BRKT, SUPPORT IS300 1
4LA010-021 BRKT, LOWER SUPPORT IS300 1
4LA010-044 BRKT, 5/16" S/C MOUNT IS300 1
4LA017-011 SPACER, IDLER, 1.060"L IS300 1
7A375-100 3/8-16 x 1" G5 HHCS PLT 2
7A375-100 3/8-16 x 1" G5 HHCS PLT 1
7A375-178 3/8-16 x 1-3/4" HXHD G8 5
7A375-276 3/8-16 x 2-3/4" HXHD ZINC 1
7C010-016 M10-1.25 x 16mm, FLG HD, 10.9 1
7C012-040 M12-1.75 x 40mm HXHD BOLT, CL10.9 1
7C060-070 M6-1.00 x 70mm HXHD CL8.8 PLT 2
7C080-040 M8-1.25 x 40mm, SHCS, CL12.9 1
7C080-081 M8-1.25 x 80mm, HXHD, CL10.9 1
7E010-075 #12 x 3/4" SHT METAL SCRW, HEX 3
7F375-017 3/8-16 NYLOCK NUT 2
7J006-094 6mm WASHER SS 2
7K312-001 5/16"AN WASHER, PLATED 1
7K375-040 3/8"AN960 FLAT WASHER PLATED 12
4LA112-010 INLET ASY, LEXUS IS300
8H040-035 AIR FILTER, 3.5" FLANGE, G35 OFFSET 1
7U030-036 1/2" OIL DRAIN HOSE 0.75'
7P500-001 1/2" HOSE UNION 2
7R001-006 #6 STNLS HOSE CLAMP, NARROW 3
7U031-016 5/16" PCV/VAC RUBBER HOSE 2.5'
7R004-003 STEPLESS CLAMP, 14.5-70 4
7P312-050 5/16" HOSE MENDER 1
7P312-060 ELBOW, PLASTIC 5/16" x 90° UNION 1
4LA130-026 OIL FEED LINE ASY, IS300 1
7P125-004 1/8"NPT x 90° x -4 JIC FTG STL 1
7P125-005 1/8"NPT STR x -4 JIC FTG STL 1
7P125-034 1/8"NPT x 1/8"NPT STRT T 1
7P125-125 FTG, 1/8"NPT FEM x 1/8"BSPT MALE 1
7U100-055 TIE-WRAP, 7.5" NYLON 5
7U250-090-320 OIL FEED HOSE, 32" x -4 x 90° 1
4NZ101-068 FUEL PUMP ASY, INLINE 350Z 1
5W001-045 16-14GA RING TERM., .17" HOLE 1
5W001-032 1/4" WIRE LOOM 10'
5W001-011 16-14GA RING TERM. .26" HOLE 1
5W014-030 14GA STRD WIRE BLACK .5'
7E010-075 #12 x 3/4" SHT METAL SCREW, HEX 2
7P312-017 5/16" HOSE BARB TO M10 x 1.0mm 1
7P312-082 5/16" TEE HOSE BARB 2
7R003-027 ADEL CLAMP, 1-11/16" 2
7R004-001 STEPLESS CLAMP, 15.7-70 8
PART NO. DESCRIPTION QTY PART NO. DESCRIPTION QTY.
7U031-0018 5/16" EFI HOSE, HI-PSR 5.5'
7U100-044 TIE-WRAP, 4" NYLON 10
7U100-055 TIE-WRAP, 7.5" NYLON 5
8F001-068 WALBRO INLINE FUEL PUMP, 68 GP 1
4NZ130-036 OIL DRAIN LINE ASY, 350Z 1
7P375-017 3/8"NPT x 1/2" BEADED HSE BARB 1
7R001-008 #8 STNLS HOSE CLAMP 2
7T560-001 CUTTER, 9/16" ROTABROACH 1
7T560-002 ARBOR, ROTABROACH 1
7U030-036 1/2" OIL DRAIN HOSE 1.5'
7U100-066 TIE-WRAP, 11" NYLON 5
4NZ238-088 FMU, 8:1 w/LINES, w/SPRING, 3 1
6Z010-101 FMU HOUSING (BLUE ANODIZED) 1
6Z010-111 FMU VALVE BODY (BLUE ANODIZED) 1
6Z010-131 COVER, FMU - GM 4.3 1
6Z020-130 SML DIAPHRAGM, FLUORO 1
6Z020-140 LRG DIAPHRAGM, FLOURO 1
6Z030-150 BRACKET, FMU 1
6Z040-160 PISTON, FMU 1
6Z050-191 FMU WASHER, 8:1 PLATED 1
6Z060-181 SHIM, FMU 1
6Z070-030 FMU 8:1 RING SPACER 1
6Z080-011 RETAINER, FMU SPRING GM 4.3 1
6Z090-010 SPRING, FMU GM 4.3 1
7C010-050 10-24 x .50" SHCS GR8 PLT 6
7C010-075 10-24 x 3/4" SHCS GR5 ZINC 4
7C024-025 10-24 x 1/4" PHILL HD 3
7E010-075 #12 x 3/4" SHT MTL SCRW, HEX 2
7P125-025 1/8"NPT x 5/32" HOSE, 90° 1
7P125-031 1/8"NPT x 90° x 5/16" BARB 1
7P125-032 1/8"NPT-STR, 5/16" BARB 1
7P156-082 5/32" TEE 1
7P312-005 5/16" FEM FUEL CNCT, STEEL 1
7P312-007 FUEL FTG, 5/16" GM x 5/16" HSE 1
7R004-001 STEPLESS CLAMP, 15.7-70 4
7U030-046 5/32" VACUUM LINE 7'
7U031-018 5/16" EFI FUEL HSE, HI-PSR 2.5'
7U031-018 5/16" EFI FUEL HSE, HI-PSR 1.25'
7U100-030 O-RING, FMU 1
7U100-096 ROLL PIN, 3/16" x 1/2" SS 1
5A003-130 ECU, UNICHIP QT, '02-'05 IS300 SAFE TUNE 1
8N201-330 CHARGE COOLR ASY, LEXUS IS300 1
4LA010-061 BRKT, HOOD LATCH SPRT IS300 1
4LA012-010 TUBE “A” S/C DISCHARGE IS300 1
4LA012-020 TUBE “B” S/C DISCHARGE IS300 1
4LA012-040 TUBE “D” S/C DISCHARGE IS300 1
4LA012-050 TUBE “E” S/C DISCHARGE IS300 1
4NZ012-020 TUBE, COOLER INLET, 350Z 1
7A250-074 1/4-20 x .75" HHCS PLTD 1
7A312-050 1/4-20 x 1/2" HXHD GR5 ZINC 2
7C008-050 #8-32 x 1/2" SHCS, ZINC 2
7E010-049 #10 x 3/4" HXHD SLF DRL SHT MTL 2
7F250-021 1/4-20 NYLOCK NUT ZINC PLATED 1
7J006-094 6mm WASHER SS 4
7P156-082 5/32" TEE 1
7R002-016 #16 SAE TYPE “F” SS HOSE CLAMP 2
7R002-040 #40 SAE TYPE “F” SS HOSE CLAMP 12
7R002-044 #44 SAE TYPE “F” SS HOSE CLAMP 2
7S250-025 ELBOW, 2.5"ID x 25° BLUE 5
7U030-046 5/32" VACUUM LINE 3'
7U133-090 RUBBER ELBOW, Ø1.0" x 90° 1
8D001-001 STD COMPRESS BYPASS VALVE 1
8H040-075 1" AIR FILTER BYPASS 1
8N010-210 BRKT, CLR MNT, IS300 1
8N101-350 CHARGE AIR COOLER, 350Z 1
7S300-275 REDUCER, 3.00" x 2.75" 2
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or damaged parts
immediately.
2002-2005 3.0L Lexus
Part No. 4LA218-010SQ/018SQ
®
ENGINEERING, LLC
PARTS LIST
