Vortech 1994-2001 Acura Integra GSR - Manual (Page 7)

P/N: 4HC020-030
©2004 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
28JAN04v2.1(Acura Integra LS (4HC..030v2.1))
vii
ACURA INTEGRA TYPE R 1.8L H.O.
Part No. 4HC218-090SQ
PARTS LIST
®
ENGINEERING, LLC
2E129-170 S/C,V-5 SQ G-TRIM CCW 1
4HC110-160 S/C MOUNTING PLATE ASSY 1
(SEE PAGE “V” FOR INDIVIDUAL COMPONENTS)
4HC110-180 ASSY, HONDA MAPS BLEED 1
(SEE PAGE “V” FOR INDIVIDUAL COMPONENTS)
4HC111-031 MTNG BRKT ASY, 1.8 INTEG PIN DRIVE 1
(SEE PAGE “V” FOR INDIVIDUAL COMPONENTS)
4HC114-090 ASSY, S/C DRIVE, TYPE R 1
8R101-000 PULLEY RETAINER ASSY, 4 RIB 1
2A034-333 S/C PULLEY 3.33" 4 GROOVE 1
2A044-506 BELT, K040506 TYPE R 1
4HC130-026 OIL FEED ASSY, HONDA 1
(SEE PAGE “V” FOR INDIVIDUAL COMPONENTS)
4HC130-036 OIL DRAIN ASSY, HONDA 1
(SEE PAGE “V” FOR INDIVIDUAL COMPONENTS)
4HC238-048 FMU ASSY 1
6Z110-149 FUEL MGMT UNIT, 7:1 w/SPRING, w/SLV 1
7U030-016 1/4" FUEL LINE 1.25'
7R001-004 #4 HOSE CLAMPS 2
7U030-046 5/32" VACUUM LINE 1'
7P156-082 5/32 TEE 1
7P125-037 1/8 NPT - 90° TO 1/4 BARB 1
4HC110-040 POWER STEERING ASSY, 99-00 Honda 1
(SEE PAGE “V” FOR INDIVIDUAL COMPONENTS)
4HC110-150 SUPPLEMENT, PWR STR 1997 EARLY 1
(SEE PAGE “V” FOR INDIVIDUAL COMPONENTS)
4HC212-050 AIR DISCHARGE ASSY, INTEGRA LS H.O. 1
7S275-200 2-3/4" x 2" SLEEVE 1
7S275-251 REDUCER, 2.75 TO 2.50 1
7R002-040 #40 STAINLESS HOSE CLAMP 1
7R002-044 #44 GOLDSEAL HOSE CLAMP 3
8D001-001 BYPASS VALVE 1
8H040-075 1" AIR FILTER 1
7U034-016 1" GS HOSE 0.25'
7U030-046 5/32" VACUUM LINE 3'
7P156-082 5/32" TEE 1
7R002-016 #16 HOSE CLAMP 2
8H040-040 AIR FILTER, 3.5" FLG x 5.5L 1
7P375-008 ELBOW, 3/8" x 90° UNION 1
7U030-056 3/8" PCV HOSE 3'
4HC020-030 Instruction Manual 1
008123 Decal, Sprt Cmpct, S/C, White 2
008130 License Plate Frame, Vortech 1
008445 Ext. Drive Street Pkg Assy 1
8F001-270 Fuel Pump w/Filter, GSR IN-TANK 1
8F060-310 Fuel Injector, Honda, 310 CC/Min 4
8N105-060 WATER TANK MTG ASY 94-01 INTEG 1
PART # DESCRIPTION QTY PART # DESCRIPTION QTY
4HC010-110 BRKT, H2O RESRV, HONDA 1
7A250-050 1/4-20 x .50 SHCS ZINC PLTD 3
7A250-074 1/4-20 x .75" HHCS PLTD 3
7F250-021 1/4-20 NYLOCK NUT ZINC PLTD. 3
7J006-093 6mm WASHER, PLATED 8
7J250-150 1/4" FENDER WASHER ZN PLTD 3
7P375-075 3/4" HOSE BARB UNION, BRASS 1
7P500-026 1/2NPT x Ø3/4 BARB 90° BRASS 4
7P500-078 1/2NPT x Ø3/4 HOSE FIT STRT 3
7R007-001 NYLON RATCHET CLAMP 1-1/8" 14
7U030-065 Ø3/4" x 90° RUBBER HOSE, SHORT 1
7U038-000 Ø3/4" HEATER HOSE 14
7U038-012 HOSE, Ø3/4" 90°,4x12 LEGS 2
7U038-150 HOSE, Ø3/4" x 150∞ MOLDED HOSE 2
8N055-030 TANK, WATER, TRIANGLE SHAPE 1
8N055-050 PLASTIC CAP, SURGE TANK 1
8N106-080 WATER COOLER MTG ASY 94-01 INT 1
7A250-074 1/4-20 x .75" HHCS PLTD 8
7F250-021 1/4-20 NYLOCK NUT ZINC PLTD. 8
7J250-001 1/4 WASHER, SAE, PLTD 16
7P500-026 1/2NPT x 3/4 BARB 90° BRASS 2
8N006-010 WATER COOLR, SETRAB SINGLE PAS 1
8N010-080 MTG BRKT, INTEGRA H 2 0 COOLR 2
8N107-090 WATER PMP MNTG ASY 99-00 CIVIC 1
5W001-009 16-14GA MALE SLIDE INSULATED 3
5W001-010 16-14GA FEMALE SLIDE INSULATED 2
5W001-011 16-14 GA RING TERM .26" HOLE 2
5W001-014 FUSE HOLDER 10 GA WIRE 1
5W001-015 FUSE, BLADE TYPE 20 AMP 1
5W001-019 10-12 GA BUTT CONN INSULATED 1
5W001-022 T-TAP CONN,14-16 AWG 1
5W001-042 12-10GA x 3/16" RING TERMINAL 1
5W014-030 14GA STRD WIRE BLACK 3'
7A250-050 1/4-20 x .50 SHCS ZINC PLTD 1
7J006-093 6mm WASHER, PLATED 1
7R003-027 ADEL CLAMP, 1-11/16" 1
8F001-402 PUMP, WATER, PIERBURG 1
8F101-510 H 2 O PUMP WIRING ASSY HONDA 1
8N301-160 PWR COOLR CORE ASY, LS INTEGRA 1
8N101-008 INLET DUCT, LS INTEGRA COOLER 1
8N003-011 COOLER DUCT, 5.0 INLET MACH 1
8N201-001 WELDED CORE ASSY W/ENDS S2K 1
7U125-040 HOSE, 1.25" GSR UPPER RAD. 1
7R002-024 #24 SAE TYPE F SS HOSE CLAMP 2
4GK014-010 RADIATOR PIPE, LS1 FBODY 1
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages
or damaged parts immediately.
