Vortech 1994-2001 Acura Integra GSR User Manual
Page 3
P/N: 4HC020-030
©2004 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
28JAN04v2.1(Acura Integra LS (4HC..030v2.1))
TABLE OF CONTENTS
FOREWORD ..................................................................................................................................... ii
TABLE OF CONTENTS .................................................................................................................... iii
TOOL & SUPPLY REQUIREMENTS ................................................................................................ iv
PARTS LIST - ACURA GSR .............................................................................................................. v
PARTS LIST - ACURA INTEGRA LS ................................................................................................ vi
PARTS LIST - ACURA TYPE R ......................................................................................................... vii
1.
PREPARATION/REMOVAL .................................................................................................. 1
2.
OIL FEED ............................................................................................................................. 1
3.
OIL DRAIN ........................................................................................................................... 2
4.
FUEL PUMP INSTALLATION ............................................................................................... 3
5.
FUEL INJECTOR INSTALLATION ....................................................................................... 4
6.
FUEL MANAGEMENT (FMU) INSTALLATION .................................................................... 5
7.
MAP SENSOR BLEED ASSEMBLY INSTALLATION ........................................................... 6
8.
POWER STEERING PLUMBING ......................................................................................... 7
9.
MAIN BRACKET INSTALLATION ......................................................................................... 7
10.
SUPERCHARGER MOUNTING PLATE INSTALLATION ..................................................... 8
11.
SUPERCHARGER INSTALLATION ..................................................................................... 9
12.
RADIATOR HOSE AND WATER NECK INSTALLATION ..................................................... 11
13.
STANDARD KIT DISCHARGE DUCT INSTALLATION ........................................................ 12
14.
AIR FILTER INSTALLATION ................................................................................................ 12
15.
BYPASS VALVE INSTALLATION .......................................................................................... 13
16.
SUPERCHARGER DRIVE BELT INSTALLATION ............................................................... 14
17.
POWER STEERING PLUMBING/BLEEDING ..................................................................... 15
18.
FINAL CHECK ..................................................................................................................... 16
19.
TROUBLESHOOTING ......................................................................................................... 17
iii
