Vortech 1994-2001 Acura Integra GSR - Manual (Page 6)

P/N: 4HC020-030
©2004 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
28JAN04v2.1(Acura Integra LS (4HC..030v2.1))
ACURA INTEGRA LS 1.8L
Part No. 4HC218-060SQ
PARTS LIST
®
ENGINEERING, LLC
vi
4HC110-170 S/C,V-5 SQ G-TRIM CCW 1
4HC110-170 S/C MOUNTING PLATE ASSY 1
4HC010-170 MOUNTING PLATE, 1.8 LS 1
7C080-056 8mm x 1.25 x 55mm HHD G5 BOLT 3
7K312-001 5/16" AN-WASHER 3
7A375-100 3/8-16 x 165 HXHD PCT. 5
7K375-040 3/8" AN960 FLAT WASHERS 5
4HC010-200 MNTG BRKT BLOCK, INTEGRA LS 1
4HC110-180 ASSY, HONDA MAPS BLEED 1
4HC010-180 MAPS BLEED, HONDA 1
7C040-025 M4-.7 X 25mm HXHD CS PLTD 2
7U100-058 O-RING FUEL RAIL HONDA 1
7U030-046 5/32" VACUUM LINE .67'
7P062-187 1/16 NPT X 3/16 HOSE BARB 1
7U400-001 CHECK VALVE 1
7U100-055 TIE WRAP, 6" NYLON 2
4HC114-050 ASSY, S/C DRIVE, HONDA 1
8R101-000 PULLEY RETAINER ASSY, 4 RIB 1
2A034-370 S/C PULLEY 3.70" 4 GROOVE 1
2A044-525 BELT, K040525 HONDA 1
4HC111-031 MTNG BRKT ASY, 1.8 INTEG PIN DRIVE 1
4HC011-021 MTNG BRKT, 1.8 GSR 1
4FG017-021 SPCR, LWR, ALT STY-PLT 2
7U250-022 DOWEL PIN, 1/4D x 3/4L 2
2D070-159 LARGE BEARING, EXTENDED DRIVE 2
7X100-025 WAVE WASHER-LARGE 1
7U100-084 SNAP RING, EXT DRV HOUSING 1
2D160-216 ASY, EXT DR HSNG TUBE, ACURA L 1
2D030-024 FLANGE, EXT TUBE END HONDA 1
7A312-075 5/16-18 x 3/4 HXCS GR5 ZINC 3
7K312-001 5/16 AN WASHER, PLATED 7
7A250-075 1/4-20 X 3/4 SHCS PLTD 5
4HC010-070 TENSIONER PLATE, HONDA, DOHC 1
7A250-101 1/4-20 x 1 HHCS, ZINC PLTD 4
7J006-093 6mm WASHER, PLATED 5
7A250-276 1/4-20 x 2.75" SHCS 1
7F250-020 1/4-20 HEX NUT 1
4FK116-021 IDLER PULLEY ASY. GEN II 1
7J312-000 5/16 FLAT WASHER-SAE 2
7A312-125 5/16-18 X 1-1/4 GR5 HXHD ZINC 1
4HC010-060 STUD, HONDA TENSIONER 1
7F312-018 5/16-18 NUT USS PLTD 2
7J312-875 5/16" WASHER, CUSTOM 1
4HC116-011 IDLER PULLEY ASY, HONDA 1
7C010-036 M10-1.25 x 35mm FLANGED 2
7J010-002 10mm WASHER, ZINC PLATED 2
2D170-226 ASY, DRIVE SHAFT, INTEGRA LS 1
4HC010-130 TOP PLATE, HONDA 1.6/1.8 1
7A312-525 5/16-18 x 5.25 HXCS GR8 ZINC 4
2D070-281 COUPLING, FLG, 3-PIN DRIVE 2
7U250-125 DOWEL PIN, 1/4D x 1.25L 6
2D070-260 COUPLING, DRIVE, COMPOSITE 1
7U100-070 KEY, 3/16 SQUARE x 7/8 LONG 2
7B375-075 3/8-24 x 3/4" GR8 HXHD BOLT 2
7J375-020 WASHER, 1.0 OD, .406 ID 2
2D030-051 HOUSING, COUPLING, EXT DRIVE SC 1
2D030-061 HOUSING, COUPLING, EXT DRIVE SH 1
7U312-101 DOWEL BUSHING, .312 x 1.00 2
2D030-026 SPACER, EXT DR HSNG, ACURA LS 1
PART # DESCRIPTION QTY PART # DESCRIPTION QTY
4HC130-026 OIL FEED ASSY, HONDA 1
7P125-125 FTG, 1/8 NPT FEM x 1/8 BSPT MALE 1
7P125-034 1/8 NPT x 1 MALE x 2 FEM 1
7P125-027 -4 TO 1/8 NPT STRAIGHT 1
7P125-026 -4 TO 1/8 NPT 90° MALE 1
7P525-067 .500 CRIMP FERRULES 2
7P250-066 #4 SWIVEL x 1/4" HOSE BARB 2
7U030-026 1/4" OIL FEED HOSE 2.67'
7U100-055 TIE WRAP, 6" NYLON 5
4HC130-036 OIL DRAIN ASSY, HONDA 1
7U030-036 1/2" OIL DRAIN HOSE 1'
7R001-008 #8 STNLS HOSE CLAMP 2
7P375-042 MALE CONNECTOR 1
4HC100-010 TUBE NUT ASSY, HONDA 1
4HC238-068 FMU ASSY 1
6Z110-141 FUEL MGMT UNIT, 6:1 W/SPRING 1
7U030-016 1/4" FUEL LINE 1.25'
7R001-004 #4 HOSE CLAMPS 2
7U030-046 5/32" VACUUM LINE 1'
7P156-082 5/32 TEE 1
4HC110-040 POWER STEERING ASSY, 99-00 HONDA 1
7A250-104 1/4-20 x 1 BHCS SS 2
7C060-016 6mm BOLTS 2
7J006-093 6mm WASHER, PLATED 2
4HC010-040 FTG, HONDA PWR STR TOP 1
4HC010-050 FTG, HONDA PWR STR PUMP 1
4HC145-060 POWER STEERING LINE ASSY, HONDA 1
7U100-088 O-RING, -015 2
4HC110-140 SUPPLEMENT, PWR STR 1997 EAP 1
4HC010-140 FTG, GSR PWR STR TOP 1
4HC010-150 FTG, GSR PWR STR PUMP 1
7U100-013 O-RING, -013 1
4HC214-060 ASSY, INTEGRA LS WATER NECK 1
4HC114-060 ASSY, INTEGRA LS WATER NECK 1
7C060-020 BOLTS, M6 x 20mm 2
7U125-040 HOSE, GSR UPPER RAD. 1
7U031-016 5/16" FUEL LINE 1.5'
4HC212-060 AIR DUCTING ASSY, INTEGRA LS 1
7S275-200 2-3/4" x 2" SLEEVE 1
7S275-251 REDUCER, 2.75 TO 2.50 1
7R002-040 #40 STAINLESS HOSE CLAMP 1
7R002-044 #44 GOLDSEAL HOSE CLAMP 3
4HC112-060 DUCT, INTEGRA LS DISCHARGE 1
8D001-001 BYPASS VALVE 1
8H040-075 1" AIR FILTER 1
7U034-016 1" GS HOSE 0.25'
7U030-046 5/32" VACUUM LINE 3'
7P156-082 5/32" TEE 1
7R002-016 #16 HOSE CLAMP 2
8H040-040 AIR FILTER, 3.5" FLG x 5.5L 1
7P375-008 ELBOW, 3/8" x 90° UNION 1
7U030-056 3/8" PCV HOSE 3'
4HC020-030 Instruction Manual 1
008123 DECAL, SPRT CMPCT, S/C, WHITE 2
008130 LICENSE PLATE FRAME, VORTECH 1
008445 EXT. DRIVE STREET PKG ASSY 1
8F001-270 FUEL PUMP W/FILTER, IN-TANK 1
8F060-310 FUEL INJECTOR, HONDA, 310 CC/MIN 4
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages
or damaged parts immediately.
