Vortech 2005-2008 C6 Corvette - Manual (Page 8)

P/N: 4GS020-010
©2009 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
12MAY09 v3.1 05-08Corvette(4GSv3.1)
viii
®
ENGINEERING, LLC
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report
any shortages or damaged parts immediately.
Corvette C6: '06-'08 LS7, '08 LS3 (V-2)
Part No. 4GS218-020SQ
PARTS LIST
2E229-250 V2 T-TRIM, H/D, ASY, C6 ZO6 1
2A036-450 S/C PULLEY 4.50" 6-GROOVE 1
2A046-926 BELT, K060926-GATES 92.6" 6-RIB 1
4GS111-021 MTG BRKT ASY 1
2A017-375 SPACER, .375", C6, IDLER 1
4GR116-300 IDLER ASY, 20MM BELT 1
4GS010-010 PLATE, C6 SPRING TENS 1
4GS010-044 PLATE, S/C MOUNTING 1
4GS011-021 C6 MTG BRKT, MACH 1
4GS017-063 BUSHING, Ø.725" x .67", SLOTTED 2
4PCV011-052 SPRING TENSIONER 1
7A375-100 3/8-16 x 1" G5 HHCS, PLT 2
7A375-124 3/8-16 x 1-1/4" HxHD G5 PLATED 3
7A375-276 3/8-16 x 2-3/4" HxHD ZINC 1
7A375-525 3/8-16 x 5-1/4" HxCS G5 P 3
7C010-048 M10-1.5 x 50MM FHCS ZINC 1
7C010-074 M10-1.5 x 75MM HHCS 2
7C010-038 M10-1.5 x 35MM SHCS CL10.9 1
7C010-028 M10-1.5 x 25MM, 15MM HEAD CS 1
7J010-002 10MM WASHER, ZINC PLATED 16
7F375-016 3/8-16 HEx NUT 1
4GS130-026 OIL FEED LINE ASY, C6 1
7P125-004 1/8"NPT 90° x -4 JIC FTG 1
7P250-016 M16 x 1.5MM TO -4 JIC MALE 1
7U100-055 TIE-WRAP, 6" NYLON 5
7U100-066 TIE-WRAP, 11" NYLON 2
7U250-090-260 OIL FEED HOSE, 26" x -4 x 90° 1
4GS130-036 OIL DRAIN LINE ASY, C6 1
7P375-017 3/8"NPT x 1/2" BEADED HSE BRB 1
7R001-008 #8 STNLS HOSE CLAMP 2
7T560-001 CUTTER, 9/16" ROTABROACH 1
7T560-002 ARBOR, ROTABROACH 1
7U030-036 1/2" OIL DRAIN HOSE 2.75
4GS112-010 AIR INTAKE ASY, C6 1
4GS012-010 DUCT, INLET 1
7P375-008 ELBOW, 3/8" x 90° UNION 2
7P375-113 PCV VALVE, VIPER, 3/8"-1/2" HOSE x 90° 1
7P500-003 1/2"-3/8" REDUCER BARB UNION 1
7R002-060 #60 SAE TYPE “F” SS HOSE CLAMPS 2
7S375-150 SLEEVE, 3.75" x 1.50"L, BLUE 1
7U030-056 3/8" PCV HOSE 4
7U037-030 -8 USCG FUEL HOSE, PUSH-ON 0.167"
8H040-050 AIR FILTER 3.5" FLG x 7"L 1
8N108-020 WELDED CAC ASY, C6 1
4GS112-020 DISCHARGE ASY, C6 1
4GS012-020 DUCT, S/C DISCHARGE, W/FLANGE 1
4NT012-010 DISCHARGE TUBE 1
7P062-187 1/16"NPT x 3/16" HOSE BARB 1
7P500-016 TEE, .5" x .5" x 1/16"NPT, METAL 1
7R001-008 #8 STNLS HOSE CLAMP 2
7R002-044 #44 GOLDSEAL HOSE CLAMP 5
7R002-048 #48 GOLDSEAL HOSE CLAMP 1
7R002-056 #56 SAE TYPE “F” SS HOSE CLAMP 3
7S275-055 ELBOW, 2.75" x 55° SILICONE 1
7S275-300 SLEEVE, 2-3/4" x 3", BLUE 1
7S300-275 REDUCER, 3.00"-2.75" 1
7S350-200 SLEEVE, 3-1/2" x 2", BLUE 1
7U030-046 5/32" VACUUM LINE 7
7U100-044 TIE-WRAP, 4" NYLON 5
7U100-055 TIE-WRAP, 6" NYLON 10
8D204-003 RACE BYPASS VALVE-BLUE 1
7F010-024 10-24 NYLOC NUT 1
7C010-150 10/24 x 1-1/2" SHCS 1
7J010-001 #10 FLAT WASHER 2
4GS112-070 CAC PARTS, LS7 ZO6
4GS010-050 BRKT, DRVR SIDE CAC MTG 1
4GS010-060 BRKT, PSGR SIDE CAC MTG 1
4GS010-070 BRKT, ZO6 OIL COOLER 1
4GS012-030 DUCT, CAC TO TBODY, C6 1
7A312-151 5/16-18 x 1.5" SET SCRW OVAL PT 4
7C040-008 M4-.7MM x 8MM SCHD SS 2
7F312-018 5/16-18 NUT USS PLTD 8
7J312-000 5/16" FLAT WASHER-SAE 12
7R002-064 #64 GOLDSEAL HOSE CLAMP 3
7S400-200 SLEEVE, 4" x 2"L, BLUE 1
7S400-351 REDUCER SLV 4.00" - 3.5" x 2.35"L 1
8A003-071 MAF, 3.8"ID, '05 MUSTANG GT 1
7U012-007 O-RING, FUEL INJ, 4MMx7MM 8
4GS110-110 ASY, DAMPER PIN LS7 1
4GR010-110 GUIDE, DWL PIN INST, VETTE 1
7C016-010 BOLT, LS1, M16x100MM 1
7C016-100 BOLT, M16x100 SHCS 1
7C016-125 BOLT, LS7, M16-2.0 x 125MM 1
7C016-135 BOLT, M16-2.0 x 135MM, SHCS 1
7U250-019 DOWEL PIN, 1/4" x 1/2" +.001" 1
7U250-026 DRILL BUSHING, 1/4"ID, 3/8"OD, 1/2"L 1
8F060-066 FUEL INJECTOR, 66LBS SHORT 8
5W001-051 HARNESS, INJ ADAPT 99+ FORD 4V 8
4GS020-010
CORVETTE V8 MANUAL 1
4GS110-100 RADIATOR SHROUD ASY, C6 1
4GS010-100 SPT, DRIVER SIDE RAD. C6 1
4GS010-110 SPT, PSGR SIDE RAD. C6 1
4GS010-120 SIDE PANEL, PSGR SIDE RAD. C6 1
4GS010-130 SIDE PANEL, DRIVER SIDE RAD. C6 1
4GS010-140 SIDE PANEL, LWR, DRIVER SIDE RAD. C6 1
7U600-656 WTHR-STRIP, .078"-.093" EDGE, .656" BULB 4
7C010-052 10-24 x 1/2" SS BHCS 4
7F010-024 10-24 NYLOCK NUT 4
2A017-752-03 SPACER, .750"OD x .927"L 4
7C080-051 M8-1.25 x 50MM HxHD CL10.9 4
7J312-000 5/16" FLAT WASHER-SAE 4
5A003-040 DIABLO PREDATOR, '06-'07 GM 1
008110 SMALL SILVER DIE CUT DECAL 2
008130 LICENSE PLATE FRAME, VORTECH 1
008444 S/C STREET PACKAGE ASY 1
PART NO. DESCRIPTION QTY. PART NUMBER DESCRIPTION QTY.
