Vortech 2005-2008 C6 Corvette - Manual (Page 10)

P/N: 4GS020-010
©2009 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
29MAY09 v3.1 05-08Corvette(4GSv3.1)
1
A. Disconnect negative cable at the battery.
B. Remove the air filter assembly and all ducting
up to the throttle body.
C. Remove Mass Air Flow (MAF) sensor from
factory air inlet and set aside.
D. Remove both of the coil/fuel rail covers on
top of the engine and set aside.
E. Remove the accessory drive belt.
F Remove the accessory drive belt spring ten-
sioner. The belt and tensioner will not be re-
used.
G. Remove the four screws securing the plastic
upper radiator support to the top of the frame
rails. Remove the plastic support.
1. PREPARATION/REMOVAL
