PARTS LIST
2005-2007 Corvette LS2 C6 (V-3)
2005 Part No. 4GS218-010L/-018L, 2006-2007 Part No. 4GS218-030L/-038L
2F359-010
V3 T-TRIM, ASY
1
2A036-450
S/C PULLEY 4.50" 6-GROOVE
1
2A046-926
BELT, K060926-GATES 92.6" 6-RIB
1
4GS111-021
MTG BRKT ASY
1
2A017-375
SPACER, .375", C6, IDLER
1
4GR116-300
IDLER ASY, 20MM BELT
1
4GS010-010
PLATE, C6 SPRING TENS
1
4GS010-044
PLATE, S/C MOUNTING
1
4GS011-021
C6 MTG BRKT, MACH
1
4GS017-063 BUSHING, Ø.725" x .67", SLOTTED
2
4PCV011-052
SPRING TENSIONER
1
7A375-100
3/8-16 x 1" G5 HHCS, PLT
2
7A375-124
3/8-16 x 1-1/4" HxHD G5 PLATED
3
7A375-276
3/8-16 x 2-3/4" HxHD ZINC
1
7A375-525
3/8-16 x 5-1/4" HxCS G5 P
3
7C010-048
M10-1.5 x 50MM FHCS ZINC
1
7C010-074
M10-1.5 x 75MM HHCS
2
7C010-038
M10-1.5 x 35MM SHCS CL10.9
1
7C010-028
M10-1.5 x 25MM, 15MM HEAD CS
1
7J010-002
10MM WASHER, ZINC PLATED
16
7F375-016
3/8-16 HEx NUT
1
4GS112-010
AIR INTAKE ASY, C6
1
4GS012-010
DUCT, INLET
1
7P375-008
ELBOW, 3/8" x 90° UNION
2
7P375-113
PCV VALVE, VIPER, 3/8"-1/2" HOSE x 90°
1
7P500-003
1/2"-3/8" REDUCER BARB UNION
1
7R002-060
#60 SAE TYPE “F” SS HOSE CLAMPS
2
7S375-150
SLEEVE, 3.75" x 1.50"L, BLUE
1
7U030-056
3/8" PCV HOSE
4
7U037-030
-8 USCG FUEL HOSE, PUSH-ON
0.167"
8H040-050
AIR FILTER 3.5" FLG x 7"L
1
8N108-020
WELDED CAC ASY, C6
1
4GS112-020
DISCHARGE ASY, C6
1
4GS012-020 DUCT, S/C DISCHARGE, W/FLANGE
1
4NT012-010
DISCHARGE TUBE
1
7P062-187
1/16"NPT x 3/16" HOSE BARB
1
7P500-016
TEE, .5" x .5" x 1/16"NPT, METAL
1
7R001-008
#8 STNLS HOSE CLAMP
2
7R002-044
#44 GOLDSEAL HOSE CLAMP
5
7R002-048
#48 GOLDSEAL HOSE CLAMP
1
7R002-056 #56 SAE TYPE “F” SS HOSE CLAMP
3
7S275-055
ELBOW, 2.75" x 55° SILICONE
1
7S275-300
SLEEVE, 2-3/4" x 3", BLUE
1
7S300-275
REDUCER, 3.00"-2.75"
1
7S350-200
SLEEVE, 3-1/2" x 2", BLUE
1
7U030-046
5/32" VACUUM LINE
7
7U100-044
TIE-WRAP, 4" NYLON
5
7U100-055
TIE-WRAP, 6" NYLON
10
8D204-003
RACE BYPASS VALVE-BLUE
1
7F010-024
10-24 NYLOCK NUT
1
7C010-150
10-24 x 1-1/2" SHCS
1
7J010-001
#10 FLAT WASHER
2
4GS112-030
CAC PARTS, LS2 C6
1
4GS010-050
BRKT, DRVR SIDE CAC MTG
1
4GS010-060
BRKT, PSGR SIDE CAC MTG
1
4GS012-030
DUCT, CAC TO TBODY, C6
1
7A312-151
5/16-18 x 1.5" SET SCRW OVAL PT
4
7F312-018
5/16-18 NUT USS PLTD
8
7J312-000
5/16" FLAT WASHER-SAE
12
7R002-056
#56 HOSE CLAMP
3
7R002-060
#60 HOSE CLAMP
2
7R002-064
#64 GOLDSEAL HOSE CLAMP
1
7S400-350
REDUCER, 4" x 3.5"
1
7S400-351
REDUCER SLV 4.00" - 3.5" x 2.35"L
1
8F060-048
FUEL INSTALLATION, 39LB EV6
8
7C060-025
M6-1.00 x 25MM, HEx
4
2A017-031
SPACER, .38"
4
7U012-007
O-RING, FUEL INJ, 4MMx7MM
8
4GR110-110 ASY, CORVETTE DAMPER PIN
1
4GR010-110
GUIDE, DWL PIN INST. VETTE
1
7C016-010
BOLT, LS1, M16 x 2.0mm
1
7C016-100
BOLT, M16-2.0 x 100mm, SHCS
1
7U250-026
DRILL BUSHING, 1/4"ID, 1/2"L
1
7U250-019
DOWEL PIN 1/4" x .5"L
1
4GS020-010
CORVETTE V8 MANUAL
1
4GS110-100 RADIATOR SHROUD ASY, C6
1
4GS010-100
SPT, DRIVER SIDE RAD. C6
1
4GS010-110
SPT, PSGR SIDE RAD. C6
1
4GS010-120
SIDE PANEL, PSGR SIDE RAD. C6
1
4GS010-130
SIDE PANEL, DRIVER SIDE RAD. C6
1
4GS010-140
SIDE PANEL, LWR, DRIVER SIDE RAD. C6
1
7U600-656
WTHR-STRIP, .078"-.093" EDGE, .656" BULB
4
7C010-052
10-24 x 1/2" SS BHCS
4
7F010-024
10-24 NYLOCK NUT
4
2A017-752-03
SPACER, .750"OD x .927"L
4
7C080-051
M8-1.25 x 50MM HxHD CL10.9
4
7J312-000
5/16" FLAT WASHER-SAE
4
5A003-039
DIABLO PREDATOR, 2005
1
5A003-040
DIABLO PREDATOR, 2006
1
008110
SMALL SILVER DIE CUT DECAL
2
008130
LICENSE PLATE FRAME, VORTECH 1
008447
S/C STREET PACKAGE ASY
1
009035
LUBE ASSY
1
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report
any shortages or damaged parts immediately.
