Vortech Ford SVT Contour/Mercury 2.5L V6 Cougar - Manual (Page 8)

P/N: 4FS020-010
©2002 Vortech Engineering, Inc.
All Rights Reserved, Intl. Copr. Secured
11JAN02 V2.0
(Cougar (4FS V2.0))
viii
1999-2000 FORD SVT CONTOUR/
MERCURY 2.5L V-6 COUGAR
Part No. 4FS218-020SQ/028SQ
PARTS LIST
®
ENGINEERING, LLC
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any short-
ages or damaged parts immediately.
2D118-050 V-9 F-TRIM SQ SUPERCHARGER ASSY 1
4FS111-021 SUPERCHARGER MTG. ASSY. 1
4FS110-034 S/C Mtg Plate Assy. Cougar 1
7K312-001 5/16” Flat Washer, AN 11
7A312-175 5/16” X 18 X 1.75” Bolt 6
7C080-045 8mm X 1.25 x 45mm Bolt 5
4FS111-034 Supercharger Drive Assy. 1
2D160-214 Tube Assy. Ext Drive 1
2D170-224 Assy. Ext Drive, Cougar/GSR 1
4FS110-010 BRG MTG PLATE ASSY. 1
7F437-000 7/16” - 14 Hex Nut 1
7J438-081 7/16 SAE Washer Plated 1
2A017-037 Spacer, Threaded Hex, 1.490” 2
2A017-038 Spacer, Threaded Hex, 1.735” 1
2A017-039 Spacer, Idler Plt, 1.926” 1
4FS010-020 Plate, Idler Mounting 1
2A017-044 Spacer, Idler, .509” 1
2A046-923 Belt, K060923-Gates Cougar 1
4FA016-150 Idler Pulley, 6Rib 3.5” Flanged 1
7A312-075 5/16-18 x 3/4 HXCS GR5 Zinc 12
7C060-025 M6 x 1.00” x 25mm Hex 1
7J006-093 6mm Washer, Plated 1
7C080-025 8mm x 1.25 x 25 HXHD 3
7K312-001 5/16” AN Washer 18
7C080-056 8mm x 1.25 x 55 HXHD Zinc Plt. 1
7C080-075 8mm x 1.25 x 75 Stud 2
7C080-100 8mm x 1,25 x 100 HXHD Zinc Plt. 1
2A036-333 S/C Pulley, 3.33” 6 Groove 1
8R101-001 Pulley Retainer Assy. 6 Rib 1
7A437-201 7/16-14 x 2.00 HXHD Zinc Plt 1
7F250-040 1/4-20 Nut Plate 2
7A250-101 1/4-20 x 1 HXHD CPSC 3
7J250-001 1/4 SAE Washer, Pltd. 4
2D070-159 Large Bearing, Extended 2
7U100-084 Snap Ring, V9 1
7X100-025 Wave Washer - Large 1
2D030-041 Brg Hsg, Ext Drive, Mach 1
2A017-093 Spacer, S/C Ply, .093” 1
7A312-079 5/16-18 x .75 Button Hd Plt. 1
7F250-021 1/4-20 Nylock Nut Zinc Pltd. 1
4FS112-010 AIR INTAKE ASSY. 1
4FS112-001 Air Inlet Duct 1
8H040-010 Air Filter 1
4FS110-070 MAF/Filter Mount Brkt 1
7U035-002 3” Flex Hose x 3.5” Long 1
7R002-044 Flex Hose Clamps 2
7S300-002 3” Cast Elbow 1
7U030-056 3/8” Crank Vent Hose x 18” 1
7P375-098 3/8” Crank Vent Hose TEE 1
7U100-052 IAT Sensor Grommet 1
7P750-102 90
°
Bypass Hose Fitting 1
7P250-047 1/4 NPT x 90 ° x 3/8” Vent Hose Fitting 1
Part Number Description Quantity Part Number Description Quantity
7R002-056 Inlet Duct Clamp 1
7S300-200 3” Sleeve to MAF 1
7R002-048 Clamps to MAF/Sleeve 2
4FS010-040 Fuse Box Bracket 1
7A250-101 1/4-20 x 1 SHCS 4
7F250-021 1/4-20 Nuts 4
7J250-001 1/4 Washers 8
7E010-046 #8 SHTMTL Screw x .75 3
7J008-001 #8 Washers 3
4FS212-020 AIR DISCHARGE ASSY. 1
4FS112-020 Discharge Duct 1
7P375-106 PCV Valve 1
7S250-200 2.5” Sleeves 2
7R002-040 Sleeve Clamps 4
8D001-001 Bypass 1
7U034-016 1” HOSE X 4.25” (Inlet) 1
7U034-016 1” HOSE X 4.25” (Outlet) 1
7R002-016 Bypass Clamps 4
7U030-046 Vacuum Hose x 18” 1
7P156-082 TEE 1
7U133-060 .75 x 90
°
Elbow For IAC 1
7R002-010 #10 Clamps 2
7S275-251 2.75/2.50 Reducer 1
7R002-044 #44 Clamp 4
4FS130-026 OIL FEED ASSY. 1
7U030-026 1/4” Oil Feed Hose x 26” 1
7P525-067 .525 Crimp Ferrules 2
7P250-066 -4 Swivel x 1/4 Hose 2
7P125-026 #4 x 90 x 1/8 NPT 1
7P250-036 #4 x 1/4 NPT Straight 1
4FS130-036 OIL DRAIN ASSY. 1
7R001-008 #8 Stnls Hose Clamp 2
7P375-047 3/8 NPT x 2” Nipple 1
7U030-036 1/2” Oil Drain Hose x 14” 1
7U100-055 Tie Wrap, 6” Nylon 1
4FS100-010 TUBE NUT ASSY. 1
7P375-004 1/2” Male SAE Flare x 3/8 NPTF 1
4FS114-010 WATER TUBE ASSY. 1
4FS017-021 Radiator Spacer, Left 1
4FS017-031 Radiator Spacer, Right 1
4FS017-011 Radiator Spacer, Round 2
7C060-035 M6 x 1.0 x 35 Bolt 2
7C060-045 m6 x 1.0 x 45 Bolt 2
7J006-093 M6 Washer 4
7P625-017 ø5/8 x 3.25 Union (Surge Tank) 1
4FS014-011 Water Crossover Tube (modified) 1
7R001-008 #8 Hose Clamps 2
4FS120-020 ECM MODULE COUPON ASSY. 1
8F060-038 FUEL INJECTORS 6
SW001-051 JUMPER HARNESS 6
4FS020-010 INSTRUCTION MANUAL 1
