User Manual
b. Select Use the following IP configuration to manually specify the IP address.
(1) IP Address: If DHCP is not used to assign IP addresses, enter it manually in
decimal-dot notation. The IP address must be set to a unique value in the
network.
(2) Subnet Mask: A subnet mask defines the number of bits taken from the IP
address that are assigned for the host part.
(3) Default Gateway: The gateway address, or router, allows communication to other
LAN segments. The gateway address should be the IP address of the router
connected to the same LAN segment as the unit. The gateway address must be
within the local network.
(4) DNS Server: The DNS server allows the name of a remote machine to be
resolved automatically. Enter the IP address of the DNS server. If the device is
DHCP enabled, the DHCP server provides the DNS server IP address, which will
override this configured value. Note: This setting is applicable only in Manual
Connection mode.
c.
SNMP
(1) Select Enable or Disable to enable or disable the SNMP protocol.
(2) SNMP Manager: Specify the IP address of the SNMP manager.
(3) The SNMP MIB may be downloaded on the Downloads tab on this page:
d. Ethernet Configuration
(1) Auto Negotiate: With this option, the Ethernet port auto-negotiates the speed and
duplex with the hardware endpoint to which it is connected. This is the default.
(2) Speed: The speed of data transmission. The default is 100 Mbps. This option is
only available when Auto Negotiate is not enabled.
(3) Duplex: The direction of data transmission. The default is Full. This option is only
available when Auto Negotiate is not enabled.
