SEQ/SEQ-1U User Manual
Software Version 2.0
9. Specifications
Parameter Specification
Load Rating 20 Amps at 120 Volts
Maximum Load Inrush Energy 1400 Joules total during power-up
Surge Let-through Voltage (6000 Volt Surge) 0 Volts
UL 1449 Adjunct Classification Test Results 1000 Surges, 6000 Volts, 3000 Amps, B3 pulse;
measured suppressed voltage, 170 Volts; no failures
Maximum Applied Surge Voltage 6000 Volts *
Maximum Applied Surge Current Unlimited (due to current limiting) *
Maximum Applied Surge Energy Unlimited (due to current limiting) *
Endurance (C62.41-1991 category B3 pulses) 1 KV > 500,000; 3 KV > 10,000; 6 KV > 1000
EMI/RFI Filter Normal mode (50Ω load) > 30 dB 100 KHz - 50 MHz
Common Mode (50Ω load) > 20 dB 1 MHz - 50 MHz
Under-Voltage Auto Shutdown Adjustable from 90V to 110V
Over-Voltage Auto Shutdown Adjustable from 130V to 150V
Delay Time per Bank 1 – 40 seconds in 1 second increments
Voltmeter Accuracy ± 2%
Remote Control Input Voltage 5 – 30 VDC
Current Draw 4 mA Maximum
Auxiliary Relay Contact Rating 30V DC at 1A
Contact Closure Max Resistance 100 Ω
12V DC Output Max Current 40 mA
Dimensions SEQ 19” W x 10.5” D x 3.5” H (2 RU)
SEQ-1U 19” W x 12.25” D x 1.75” H (1 RU)
Weight SEQ 16 lb.
SEQ-1U 13 lb.
Temperature Range: 5C to 35C
Humidity Range 0% to 95% R.H. Non-condensing
Agency Listings UL 1449 3 rd Edition (SEQ-1U Pending)
UL 1283 5 th Edition (SEQ-1U Pending)
CSA C22.2 No.8-M1986 (R2008) (SEQ-1U Pending)
* 1.2 x 50 microsecond industry standard combination wave surge as per IEEE C62.41
*CAUTION: Do not install this device if there is not at least 10 meters (30 feet) or more between the electrical
outlet and the electrical service panel.
