Page 27
22
Installation
StorCase Technology, Inc.
InfoStation 14-Bay U320 Installation Guide - Rev. A00
Installing the SNMP Module into the InfoStation
CAUTION:
The SNMP Module contains NO USER SERVICEABLE parts inside the unit.
Refer ALL servicing to qualified service personnel!
NOTES:
While performing the steps in this section, work on a soft surface to
prevent excessive shock to the SNMP Module and InfoStation chassis.
The SNMP Module is hot-swappable. The chassis may remain on when
removing and installing the SNMP Module. Refer to the InfoStation SNMP
Module User's Guide for further information.
The InfoStation UI firmware must be at least Rev. 2.0.12 to support the
SNMP Module. The latest InfoStation UI firmware can be downloaded from
the StorCase web site.
1.
Carefully slide the SNMP Module into the chassis and tighten the two (2) captive
screws (Figure 23).
Figure 23: Installing the SNMP Module into the InfoStation
SNMP
Module
InfoStation
Chassis
