StorCase Technology 14-Bay 4U SCSI Ultra320 User Manual
Page 24
InfoStation 14-Bay U320 Installation Guide - Rev. A00
StorCase Technology, Inc.
Installation
19
#6-32 Phillips
F.H. Screw
Blank
Plate
Blower
module
IFSII_DR8
Figure 19: Installation Location of RAID Battery Backup Unit
RAID Battery
Backup Unit
Blower
Module
Thumbscrew
IFSII_DR9
Figure 20: Installing the RAID Battery Backup Unit into the Blower Module
