StorCase Technology 14-Bay 4U SCSI Ultra320 User Manual
Page 13
8
Installation
StorCase Technology, Inc.
InfoStation 14-Bay U320 Installation Guide - Rev. A00
Figure 7: Installing the Power Cord Retainer Clip
IFS14_24
Power Supply
Module
Retainer
Clip
AC Power
Cord
Retainer
Clip
1
2
3
Retainer
Clip
AC Power
Cord
NOTE:
When removing the power supply module, make sure the retainer clip (if installed)
is not blocking the power supply module handle (handle pivots outward).
Damage to the retainer clip may occur otherwise.
