InfoStation 14-Bay U320 Installation Guide - Rev. A00 StorCase Technology, Inc.
Installation 15
Dual RAID Controller Module Unit Installation
CAUTION: Remove ALL power from the InfoStation before installing the Dual RAID
Controller Module unit. The RAID Controller Module contains NO USER
SERVICEABLE PARTS inside. Warranty is VOID if module is opened.
Refer ALL servicing to qualified service personnel!
NOTES: The installation, configuration, and use of the Dual RAID Controller Module
option for the StorCase InfoStation chassis requires a certain level of
expertise and experience on the part of the user/integrator. Since there
are many configuration options and variables (ie. host platforms, applica-
tions, etc), only general guidelines will be discussed in this User's Guide.
Refer to both the InfoStation User's Guide and InfoStation Dual RAID
Controller Module User's Guide for additional operating and installation
information. Also refer to the disk manufacturer's documentation for in-
formation regarding the disks.
While performing the steps in this section, work on a soft surface to prevent excessive shock
to the RAID Controller Module and InfoStation chassis. Also refer to the manufacturer's
documentation provided with the drive(s). A #2 Phillips and a flat blade screwdriver will be
required.
Removing the InfoStation Module Option Cover Plate
CAUTION: Remove ALL power from the InfoStation before removing any panels or
cover plates. The InfoStation contains NO USER SERVICEABLE PARTS
inside the unit. Refer ALL servicing to qualified service personnel!
NOTE: Cover plate must be installed if module slot is left empty. Installation of the
cover plate is necessary for proper cooling inside chassis.
1. Loosen and remove the four (4) #6-32 Phillips F. H. screws securing the module option
cover plate to the InfoStation chassis (Figure 15). Remove the cover plate (save the
cover plate and screws for future use).
2. To reinstall cover plate, simply reverse the above mentioned steps.
