Kingston Technology Company DE300i-S User's Guide - Rev. B00
14 Installation
Table 2: J3A, J3B, J3C Option Pin Signal Descriptions
PIN Signal Function
1 ID0 SCSI ID
2 GND Ground
3 ID1 SCSI ID
4 GND Ground
5 ID2 SCSI ID
6 GND Ground
7 Not Used
8 Not Used
9 DT Disable On Board Terminator
10 GND Ground
11 RLEDC Remote LED Cathode
12 RLEDA Remote LED Anode
13 DFAULT Force Drive Fault Signal to Display
14 GND Ground
15 SYNC Drive Synchronization Signal
16 GND Ground
17 TPWR Terminate Power To/From SCSI Bus
18 GND Ground
19 WTP Reserved
20 GND Ground
21 LKA Disable Isolator Functions
22 LKB Disable Isolator Functions
