12

Installation

StorCase Technology, Inc.

DE200i-SWC160 User's Guide - Rev. B01

Table 2: Option Pins 13-16 Drive Motor Control

NOTE:

Option Pins 13-16 (Table 2) are used to remotely access the disk drive's

motor control options. Refer to the documentation provided by the drive

manufacturer for further information.

Open

Open

Motor spins up on "Power On"

Open

Closed

Motor spins up only if SCSI

"Start" command is received

Closed

Open

Drive motor starts spinning up

approximately 12 seconds x the

SCSI ID number for each target

drive (12 second minimum)

Closed

Closed

Reserved

Closed = Jumper installed
Open = Jumper removed

DYST

RMST

Function
