Installation 11
DE200i-SWC160 User's Guide - Rev. B01 StorCase Technology, Inc.
1 ID0 SCSI ID
2 GND Ground
3 ID1 SCSI ID
4 GND Ground
5 ID2 SCSI ID
6 GND Ground
7 ID3 SCSI ID
8 GND Ground
9 FFAULT Fan Failure LED/Alarm Enable
10 FFAULT Fan Failure LED/Alarm Enable
11 SYNC Drive Synchronous Signal
12 GND Ground
13 RMST Remote Start (see Table 3)
14 GND Ground
15 DYST Delay Start (see Table 3)
16 GND Ground
17 DISABLE FFAULT/Alarm Temporary Disable
18 DISABLE FFAULT/Alarm Temporary Disable
19 FAN1 Fan 1 Power Enable
20 FAN1 Fan 1 Power Enable
21 FAN2 Fan 2 Power Enable
22 FAN2 Fan 2 Power Enable
PIN Signal Function
Table 1: Option Pin Connector (W1) Signal Descriptions
NOTES: The DE200i-SWC160 has a Fan Fault LED and Alarm feature in the event of a fan
failure. In the event of a single fan failure, this Fan Fault LED and Alarm feature may
be temporarily disabled (with an installed jumper on Pins 17 & 18).
With this jumper installed, the Fan Fault LED and Alarm will still function in the event
of total fan failure.
Refer to section "Receiving Frame (Rear)" in the Introduction for further information.
This jumper must be removed once the faulty fan is replaced! Refer to Appendix
D for further information.
