Replacement parts, Dimensions – SOR 1540 Side Mounted Non-Bleed Pneumatic Level Switch User Manual
Page 4
4/4
Form 1306 (04.13) ©SOR Inc.
14685 West 105th Street, Lenexa, KS 66215
913-888-2630 800-676-6794 USA Fax 913-888-0767
Registered Quality System to ISO 9001
Printed in USA
sorinc.com
Designator
Description
3130040
20’ Remote Cable with two cable crimps*
3100152
Float
9227012
Float & Arm Assembly
9227024
Manual Check Accessory (uses Viton GLT O-ring) (MC)*
9227025
Manual Check Accessory with remote 20’ cable (MD)*
Replacement Parts
* Unit must have originally been supplied with MC or MD option.
Dimensions are for reference only. Contact the factory for
certified drawings for a particular model number.
Linear = mm/inches
Drawing 0091448
Dimensions
14685 W 105TH S
72.8
2.87
19.8
0.78
36
1.4
ACTUATION
28
1.1
FLOAT
TRAVEL
71
2.8
ACTUATION
56
2.2
32.5
1.28
WRENCH
FLATS
18.4
0.72
31.0
1.22
72.2
2.84
14.3
0.56
12.7
0.50
145.3
5.72
MOUNT THIS SURFACE
VERTICAL ±5°
1/4"NPTF
INLET
1/4"NPTF
INLET
MOUNT THIS AXIS
HORIZONTAL ±5°
2" NPTM PROCESS
CONNECTION
MANUAL CHECK CABLE
20 FT LONG
MD OPTION ONLY
MANUAL CHECK
MC or MD OPTION
