Linear = mm/inches – SOR Weatherproof Low Range User Manual
Page 7

Form 536 (08.13) ©SOR Inc.
7/8
*197.8
7.79
*57.4
2.26
40.5
1.59
28.6
1.12
36.5
1.44
69.9
2.75
103.4
4.07
25.1
0.99
99.9
3.94
103.7
4.08
CLEARANCE SLOTS
FOR 6.4
0.25 HARDWARE WITH
63.5
2.50 MIN TO
76.2
3.00 MAX
MOUNTING CENTERS
26.2
1.03
70.3
2.77
7.1
0.28
ELECTRICAL
CONNECTION
3/4 NPTF
WITH 457.2
18.00 MIN
LENGTH WIRES
PROCESS CONNECTION
HIGH
PROCESS
CONNECTION
1/4 NPTF
LOW
Linear = mm/inches
Drawing 0091359
Weathertight — NEMA 4, 4X, IP65
Piston Number 24
Designator:
RB,
RH
