SOR Mini-Hermet User Manual
Page 5
Form 168 (05.13) ©SOR Inc.
5/8
Dimensions are for
reference only.
Contact the factory
for certified drawings
for a particular model
number.
Special Conditions for Safe Use ATEX, TIIS units
Dimensions
Linear = mm/inches
Drawing 0090119
The permanently attached cables are to be suitably terminated and protected
from
impact.
To minimize the risk of electrostatic discharge, clean only with a damp cloth.
