SOR Big Hermet Explosion Proof, Hermetically Sealed, Pressure Switch User Manual
Page 8
8/8
Form 280 (04.13) ©SOR Inc.
14685 West 105th Street, Lenexa, KS 66215
913-888-2630 800-676-6794 USA Fax 913-888-0767
Registered Quality System to ISO 9001
Printed in USA
www.sorinc.com
Process
Connection Size
Piston Number
12, 52
4, 54
6, 5, 9, 1, 56
1/4 NPT(F)
Shown
Shown
Shown
1/2 NPT(F)
Shown
Shown
Add 13.2
0.52
3/4 NPT(M)
N/A
N/A
Add 23.1
0.91
1 NPT(F)
Add 5.6
0.22
N/A
N/A
1 NPT(M)
N/A
Add 46.0
1.81
N/A
2NPT(F)
Add 25.4
1.00
N/A
N/A
Length A 1/4 NPT(M)
Add 29.7
1.17
Add 29.7
1.17
Add 29.7
1.17
Length A 1/2 NPT(M)
Add 38.9
1.53
Add 38.9
1.53
Add 38.9
1.53
