Rocktron Utopia B300 - Manual (Page 80)

80
Specifications
Maximum Output Level +4 dBu
Output Jacks ¼" Left and Right.
Headphone Jack 1/8" Stereo (Load Impedance 32 Ohm Min)
Important: Listening to any sounds at levels
above 85 dBu may cause hearing damage!
Due to high output capabilities present in
the HEADPHONE OUTPUTS it is recom-
mended to only use headphones that have
an integrated volume control. You may also
set the volume when the display is showing
a preset name by turning the PARAMETER
ADJUST control which is mapped directly
to the MASTER VOLUME of the B300.
Aux Input Jack 1/8" Stereo
Power Requirements 9VAC / 2.9A min. Depending on where you
are located in the world you may receive a
2 .9A, 3A, 3.5A adapter with USA or Euro
style plugs.
Dimensions With toe of expression pedal down
20 1/4" Wide x 9" Deep x 3 1/4" Tall
510mm Wide x 228mm Deep x 83mm Tall
With toe of expression pedal up
20 1/4" Wide x 9" Deep x 4 7/8" Tall
510mm Wide x 228mm Deep x 124mm Tall
Weight 8.5lbs
3.85kg
Input Impedance 1M Ohm
Maximum Input Level 0 dBu
Input Jack ¼" mono
9. SPECIFICATIONS
