47
FUNCTION PARAMETER LIST RANGE
(via FUNCTION SELECT) (via PARAMETER SELECT) (via PARAMETER ADJUST)
GLOBAL OUTPUT (Output Level) Stereo, Mono
SPKR XTR (Speaker Exciter Lock) Unlock, Lock Off, Lock L, Lock B
HUSH OFFSET -10(dB) to +30(dB)
MASTER VOLUME -40(dB) to +6(dB)
MIXER VOLUME (Volume Level) 0 to 127
LEFT OUT LVL (Left Channel Output Level) OFF to +4(dB)
RIGHT OUT LVL (Right Channel Output Level) OFF to +4(dB)
MIX (Direct/Effect Mix Level) DIR <0 to 100> EFF
DIR PAN (Direct Signal Panning) L <0 to 100> R
DELAY LVL (Delay Signal Level) OFF to +4(dB)
REVERB LVL (Reverb Signal Level) OFF to +4(dB)
PREAMP CHANNEL DEEP, NORM, BRITE, DIST
GAIN (Gain Level) 0 to 10
VARIAC ADJUST (Variac Level Adjustment) -6(dB) to 0(dB)
BASS (Bass Level) 0 to 10
MID (Midband Level) 0 to 10
TREBLE (Treble Level) 0 to 10
PRESENCE (Presence Level) 0 to 10
BRIGHT In, Out (DEEP, NORM & BRITE)
SCOOP Out, In (DIST Only)
MASTER 0 to 10
SYMMETRY -28(dBu) to +6(dBu) default is 0.0
(dBu) (DIST Only
POLARITY + or - (DIST Only)
DX-FILTER 0 to 49 (DIST Only)
MIX DIR <50> DIS (DIST Only)
DIR LPF 0-64 (DIST Only)
HUSH HUSH (Hush In/Out) Out, In
EXP THRESH (Expander Threshold Level) -90(dB) to -27(dB)
EXCITER EXCITER (Speaker Exciter Status) Off, Left, Both
SPKR CURV (Speaker Curve) A, B, C, D, E
DEFINITION -15 to +15
SONIC BOOM -15(dB) to +15(dB)
COMPRESSOR COMPRESSOR (Compressor In/Out Status) Out, In
COMP THRESH (Compression Threshold) -24(dB) to 0(dB)
COMP ATTACK (Compression Attack) 1MS, 2MS, 4MS, 8MS, 16MS,
25MS, 50MS, 75MS
COMP RELEASE (Compression Release) .05S.to 2.0S
EFFECTS LOOP EFX LOOP Out, In
WAH-WAH WAH-WAH (Wah-Wah In/Out Status) Out, In
WAH FREQ (Wah Frequency) 310Hz to 2.6kHz
PHASER PHASER (Phaser In/Out Status) Out, In
DIR/EFF MIX DIR <0 to 100> EFF
DEPTH (Amount of Modulation) 0 to 100
P-RATE (Phaser Rate of Modulation) 0 to 254
RESONANCE (Amount of Feedback) 0 to 100
STAGES (Number of Stages) 4, 6
7. Function - Parameter - Range List
