50
8. Operating the UTOPIA B300
When in PRESET MODE the LEDs will be lit "GREEN" and the display will show the following:
Top line of display will show:
BANK - Displays the Preset Bank you have selected. - in the example below - B00
PRESET TITLE - This is the NAME of the preset - in the example below - BIG WAH WAH
Bottom line of display will show:
PRESET NUMBER - This is the number of the preset - in the example below - 4
EFFECTS USED IN PRESET - in the example below - Chr-Dly-Rev (Chorus-Delay-Reverb)
8. Display Description
The LCD display on the Utopia B300 provides you with the information about the preset you are in:
When in 2ND FUNCTION MODE the LEDs will be lit "YELLOW" with the 2nd Cancel (button 9)
LED lit "RED"
The display will remain the same as in preset mode with the following exceptions:
1) If Tru-Bypass has been selected for the Effect On/Off 2nd Function then Tru-Bypass will be shown
on the bottom line if selected.
2) If you have pressed the MUTE/TUNER button number 3, the TUNER will be shown in the display
When in PRESET EDIT MODE (accessed by turning the FUNCTION SELECT knob) the display will
show the following:
Top line of display will show the FUNCTION selected - in the example below ***PREAMP***
Bottom line of display will show the first PARAMETER of the function - in the example below CHAN-
NEL NORM
B 0 0 B I G W A H W A H
4 C h R - D L Y - R E V
BANK NUMBER PRESET NAME
PRESET NUMBER EFFECTS ON PRESET
C H A N N E L N O R M
* * * P R E A M P * * *
