4555 - 58 Series
5G & 10L Pressure Reactors
- 26 -
Internal Fittings continued
Shafts
1025HC28
Upper Stub Shaft 5G Magnetic Drive
A1030HC27 Lower Shaft Assembly 5G Magnetic Drive
1025HC45
Upper Stub Shaft 10L Magnetic Drive
A1030HC44 Lower Shaft Assembly 10L Magnetic Drive
2135HC9
Shaft, 5G, Footless Magnetic Drive
2135HC21 Shaft, 10L, Footless Magnetic Drive
Impellers
1569HC
Impeller, 5G, Magnetic Drive
709HC Impeller, 10L, Magnetic Drive
A2138HC3 Impeller, 5G, Footless Magnetic Drive
A2138HC2 Impeller, 10L, Footless Magnetic Drive
709HCF Impeller Screw, ¼-20 thread (for all the above)
Stirrer Support Brackets
A1570HC
Support Bracket, 5G
A380HC3 Support Bracket, 10L
380HCF Bolt, 5/16-18 thread (for all the above)
External Fittings
94CAAD Plug, Hex Head, 1/4NPTM, T316SS
A278VBAD Valve, Straight 3/8" NPTM (Liquid Sampling)
A279VBAD Valve, Angled 3/8" NPTM x 3/8" NPTM (Gas Release)
A279VBAD Valve, Angled 3/8" NPTM x 3/8" NPTM (Gas Inlet)
420HC6
Adapter, 3/8" NPTF x A socket (Inlet Hose)
1566HC Adapter, 3/8" NPTM x 3/8" NPTF (Gas Release)
208HC18 Valve Adapter, two 3/8" NPTF (Gas Inlet/ Liquid Sampling)
208HC15 Gage Adapter, two 1/4" NPTF
209HC4 Bushing for gage and valve adapters
56HC Series Gages, 4-1/2”, psi/bar
664HC3 Magnetic Stirrer Plug (optional – use with 663HC olive)
A472E5 Thermocouple, Grounded Type J, 21-1/2"
A511E2 Thermocouple, Type J, Bayonet
A707HC2 Safety Rupture Disc Assembly without disc (See 231M)
A1750HC* Magnetic Drive (See 234M)
A1750HC2* Double Magnetic Drive Assembly (See 234M)
A2170HC* Footless Magnetic Drive (See 234M)
A2170HC2* Double Footless Magnetic Drive Assembly (See 234M)
664HC
Nut, Gland, Magnetic Drive seal
663HC* Olive, Magnetic Drive seal
2136HC Gasket, Footless Magnetic Drive
A740HC Cooling Sleeve for Magnetic Drive Assemblies
715HC O-ring, NBR (for Cooling Sleeve)
716HC Quick Disconnect (for Cooling Sleeve)
