4555 - 58 Series
5G & 10L Pressure Reactors
- 25 -
PARTS LISTS
Vessel Parts List
Consult the itemized list of part numbers provided with your reactor.
For parts made from alternate materials the following suffixes are used:
CA - Titanium
CH – Alloy C-276 CT - Inconel CC – Alloy 20Cb3
CG – Alloy B-2 CM - Monel CX - Zirconium
HEADS HEAD SEAL
1557HC Series 5G Flat Gasket 1559HC 5G Flat Gasket PTFE
3187HC Series 5G O-ring Seal 3184HCJV 5G O-ring Seal FKM
2957HC Series 10L Flat Gasket 2959HC 10L Flat Gasket PTFE
3197HC Series 10L O-ring Seal 3194HCJV 10L O-ring Seal FKM
CYLINDERS SPLIT RINGS-MOVABLE
1555HC Series 5G Flat Gasket A1556HC 5G Flat Gasket
3185HC Series 5G O-ring Seal A3186HC 5G O-ring Seal
2955HC Series 10L Flat Gasket A2956HC 10L Flat Gasket
3195HC Series 10L O-ring Seal A3196HC 10L O-ring Seal
SPLIT RINGS-FIXED HEAD COMPRESSION RINGS
A1556HC2 5G Flat Gasket 1554HC 5G Flat Gasket
A3186HC3 5G O-ring Seal N/A 5G O-ring Seal
A2956HC2 10L Flat Gasket 2954HC 10L Flat Gasket
A3196HC2 10L O-ring Seal N/A 10L O-ring Seal
ACCESSORIES
1556HCF Compression Bolts
1571HC Lift Eye (Head)
1593HC Lift Ring (Cylinder)
891DD 5/8” Comb. Wrench
Internal Fittings
Thermowell
265HC15
Thermowell, 5G 15.94”L
265HC10 Thermowell, 10L 12.12”L
48HC Thermowell, Gasket, Silver
48HCFG Thermowell, Gasket, Gold (for Special Alloy)
Dip Tube
1567HC
Series Inlet (Dip) Tube
275VBAD Male Connector to hold tube
