6772
Calorimetric Thermometer Instruction Manual
2-4
The format of an unknown balance can be determined by logging the balance output to the
printer attached to the Calorimetric Thermometer. Those protocols which send a command
string to the balance will do so while logging is active. In order for the logging to produce
meaningful results, the cable connecting the balance to the balance input port of the
Calorimetric Thermometer must be correctly wired or configured. In addition, the specifics of
the data frame, such as the baud rate, # of data bits, parity, # of stop bits and handshaking (if
used) must be the same for both the balance and the Calorimetric Thermometer.
Mettler 011/012 Interface
The ID field must contain “S_” to
indicate a stable mass. The data field
contains the current mass, right
justified, with a decimal point. The
balance should be configured to send
continuously.
Sartorious Interface
The polarity field must contain either a
“+” or a space. Leading zeros in the
data field are blanked, except for the
one to the left of the decimal point.
The stability field must contain “g_” for
the Calorimetric Thermometer to
accept a mass. The balance should be
configured to transmit data upon
receipt of the following command
string:
[ESC] P [CR] [LF]
Note:
The automatic data output option should not be used.
The Calorimetric Thermometer will send this command string once every few
seconds after the ENTER key has been pressed during a mass entry sequence.
The ENTER key should only be pressed when the mass reading is stable.
Generic Interface
The data field should consist of 9
numeric characters (0 through 9, +, -
and space) terminated with a carriage
return (CR). Leading zeros may be
blanked as spaces and are counted. Non-numeric characters are ignored and will
reset the input buffer if the data field has not been filled. Any characters received
after filling the data field and before the carriage return are ignored.
Bar Code Port
The use of barcodes in the laboratory has become a highly accurate, rapid and inexpensive
way to identify samples. When purchasing this feature, the user must supply Parr with the
MAC address of the calorimeter (found in the Software & Hardware Info menu screen). This
Field Length
ID 2
space 1
data 9
space 1
g 1
CR 1
LF 1
Field Length
polarity 1
space 1
data 8
space 1
stability 2
CR 1
LF 1
Field Length
data 8
CR 1
