2. Two-Sided Clamped Glazing

This is a simpler glazing system to install, requiring no mid-sheet
fastening, using long glazing sheets, and held in place by two
glazing profiles on both longitudinal edges. It is not as strong, and
permitted width is limited (the width direction of a multi-wall sheet
is more vulnerable to loads, span-wise, especially the thinner, square
ribbed 6 , 8 and 10 mm sheets).

Maximum Width of SUNLITE Sheets in Two Sides Clamped Flat Glazing

Twin Wall

Triple Wall

X-Lite

Uniform Load

6

8

10

8

10

16

16

25

32

35

Kg/m²

psf

mm

Inch

mm

Inch

mm

Inch

mm

Inch

mm

Inch

mm

Inch

mm

Inch

mm

Inch

mm

Inch

mm

Inch

50

10

450

18

540

21

680

27

575

19

700

25

990

39 1100 44 1250 50 1200 48 1200

48

80

16

320

13

430

17

500

20

450

15

525

18

900

36 1050 41 1100 43 1000 38

950

38

100

20

-

-

400

16

450

18

400

14

475

17

800

32 1000 35 1050 41

950

37

875

35

120

25

-

-

-

-

400

16

-

-

425

14

700

28

975

38 1000 40

900

36

800

32

Note: The notes attached to the previous table, Maximum Recommended Distances, also apply here.

3. Two-Sided Clamped Arched Glazing

1. SUNLITE sheets can be curved into arches within the permitted radius
(see “Arching Radius” on page 3) without damaging their mechanical
performance. Moreover, internal stresses induced by curving give the
sheets extra strength and rigidity in both directions, like pre-stressed
concrete elements.

2. Rigidity and support spans increase as the curve radius is reduced (down
to the minimal permitted radius). Shallow curving should be considered
to be similar to flat panels, while a deep curve significantly adds to the
bridging ability.

The table in the next page shows the growing rigidity from the curving of SUNLITE, at various uniform loads.

SUNLITE glazing

Side clamp

(Glazing profile)

Supporting rafter

Figure 4

Flat, two-sided clamped glazing

SUNLITE glazing

Clamping/glazing profile

Supporting

arch

Figure 5
