RVC 2-18 CD&
11 Appendix
70
Version 04/2012, Rev. 1.3 of 25/11/2013 • sb
Translation of the original operating manual
Pos: 196 /20 0 Ch rist/3 71 RVC-BA (PROJEK TE)/RVC 2- 18 CD plus_ 2-1 8 CDplus _HCl/11 0 Anh ang/ 110 -00 40 Kurzb edie nun gsanl eitun g @ 9 \mo d_1 320 657 4132 03_ 68. docx @ 54 035 @ 2 @ 1
11.3 Brief operating instructions
1. Switch on the system at the mains power switch down on the right side
of the unit.
2. Switch the vacuum pump and/or the cooling trap on.
3. Close the lid.
4. Starting the warm-up phase:
• Enter the set values for the warm-up phase into "menu" "options"
"Timer warm-up" und "Temperature warm-up", confirm your
entries and quit the menu.
• Press the left-hand function key "mode".
• Select the "Warm-up" menu and confirm.
• Open the lid when the warm up phase has ended.
• Install the rotors and close the lid.
5. Changing the set values for time, temperature, vacuum and safety
pressure:
• Select "menu" with the right-hand function key.
• Select "Change set values for manual mode" from the main menu.
• Select the set value by using the up/down keys and confirm with the
right-hand function key "edit".
• Change the set value by using the up/down keys and confirm with
the right-hand function key "ok".
• Quit the menu with the left-hand function key.
6. Starting the process "Evaporation manual" or "Evaporation program":
• Open the menu "Start with phase..." by pressing the left-hand
function key "mode".
• Select "Evaporation manual" or "Evaporation program" using the
up/down keys.
• Start the evaporation process by pressing the right-hand function
key.
• The function "Evaporation program" can only be selected if a
program has been created before.
The start of the evaporation process starts the following automatic
process run:
• The rotor speed increases (rotating direction left)
• At 70% of the selected maximum speed: the aeration valve closes
automatically (to avoid delays in boiling)
• At 80% of the selected maximum speed: the stop valve opens the
connection to the vacuum pump
• Further speed increase until the preselected maximum rotor speed
is reached.
7. Interrupting an evaporation process:
• Press the left-hand function key "mode".
• Select "Stop evaporation" and confirm.
Without an interruption, the evaporation process ends after the
preselected time. The following process runs automatically:
