4.4 Transport safety device
The rotational vacuum concentrator
RVC 2-18 CD
plus
is not equipped with a transport safety device.
In order to prevent the lid from getting stuck during the transport, several
layers of paper are placed between the lid and rotor chamber.
• The paper must be removed prior to the unit’s start-up.
Pos: 77 / 010 Unive rsalm odul e/ L ee rzeile @ 0\ mod _120 211 624 450 0_0. docx @ 11 4 @ @ 1
Pos: 78 / 200 Christ /37 1 RVC-BA (PROJEKTE) /RVC 2-1 8 CDpl us_2 -18 CD plus_HCl /040 La ger ung und Tr ansp ort/ 040 -00 50 Inn erb etrie bliche r T rans por t @ 9 \mo d_1 320 657 348 134_ 68. docx @ 53 955 @ 2 @ 1
4.5 On-site transport
• The RVC can be transported by a suitable number of persons who
reach under it from the sides.
CAUTION
The RVC 2-18 CD
plus
weighs approx. 14 kg!
• When lifting the RVC, always reach under it from the side. Do not grab
the unit at the plastic control panel (see figures below).
correct incorrect
Fig. 4: Lifting the RVC
• When setting the unit down, ensure that the feet are upright (see figures
below).
correct incorrect
Fig. 5: Unit feet
• If the rotational vacuum concentrator needs to be transported over long
distances, transport it in suitable packaging, and if at all possible, the
original packaging.
