Indicator lights and switches:
Red (Power) LED:
• Comes on solid on start-up (power on)
Green (Activation) LED:
• Off if no retard is active
• Solid green for the duration of the timer if either digital input active
• Blinking green if analog input active
Torque reduction settings:
• Timing retard controlled by two 10 position switches and two 16 position switches
• Retard Slope (Switch #1, 10 position switch)
• Sets the slope for the rate of change in timing retard for ramp in/ramp out
• Rate of retard is in number of degrees added/removed per cylinder event (see Appendix A)
• Controls the slope in and out (same slope is used for both ramp out and ramp in)
Position Degrees Per Cyl
Event
0
0 (no ramp)
1
2
2
4
3
6
4
8
5
10
6
15
7
20
8
25
9
30
• Max Retard (Switch #2, 10 position switch)
• Sets the maximum degrees of timing retard
Position
Max Degrees
0
5
1
10
2
15
3
20
4
25
5
30
6
35
7
40
8
45
9
50
