Page 9

Installation:
• Make sure the ignition is off before beginning installation.

• You can mount the LNC-TRM using the supplied hook and loop tape or the supplied self tapping

screws.

• Do NOT mount the LNC-TRM directly on top of the engine or near the exhaust manifolds due to heat

concerns.

• Do NOT mount the LNC-TRM in the line of site of high temperature objects such as exhaust

manifolds, turbine housings etc. If needed, put a heat shield in between the heat source and the

module.

• Do NOT install within 6” of nitrous solenoids or other

devices with strong magnetic fields.

• If you have relocated coil packs, do not run the high

voltage spark plug wires alongside the low voltage coil

pack wires. Keep the wires as far apart as possible and,

if they do have to intersect, have them intersect at right

angles.

• Keep the activation wires and the analog voltage input

wire (purple wire) away from possible sources of

electrical noise (coils, injectors, etc.)

• Disconnect the pack connectors on each side of the engine and then plug the LNC-TRM wiring

harnesses in between on each side. It does not matter which bank of cylinders each side of the LNC-

TRM harness connects to.
