Chapter 4: Using Your Stoppering Tray Dryer
Product Service 1-800-522-7658 22
Status Display will change and the Display will change to MONITOR mode.
During the RAMP cycle of the active segment, the Status Display will be as
follows:
P1 -indicates what program is
selected
PRB -shelf probes for shelf 1, 2
and 3 (If a probe is not
installed, the display shows ---)
C -°C
F -°F
TMP -system temperature
SEG
-indicates what segment is
active and ramping
VAC -system vacuum level
M
-mBar
P -Pascal
T Torr
During the HOLD cycle of the active segment the Status Display will alternately
be as follows:
P1 PRB 1=28 2=29 3=28 C
TMP=30 SEG=1H VAC=.030 M
P1 PRB 1=28 2=29 3=28 C
TMP=30 TR=4.55 VAC=0033 M TR -indicates the amount of time
remaining in the present seg-
ment. If time is 10.0 hours or
more, the time is displayed in
1/10 hours. If time is less than
10.0 hours, the time is displayed
in 1/100 hours. If the hold time
was programmed to be
indefinite, the display will show
“INDF”.
P1 -indicates what program is
selected
PBR -shelf probes for shelf 1, 2
and 3
TMP -system temperature
SEG -indicates what segment is
active and holding
VAC -system vacuum level
P1 PRB 1=28 2=29 3=28 C
TMP=30 SEG=1R VAC=.030 M
